Yokogawa VI702 Vnet/IP Interface Card

The Yokogawa VI702 is a high-performance Vnet/IP Interface Card that replaces the V1701 model. Designed for reliability and fast data exchange, it delivers 1 Gbps full-duplex communication through PCI Express architecture. Ideal for Yokogawa DCS systems, this card ensures smooth and stable industrial network performance.

Product Overview

• Manufacturer: Yokogawa
• Product No.: VI702
• Type: Vnet/IP Interface Card
• Condition: Brand New, Factory Sealed
• Warranty: 12 Months Factory Coverage
• Shipping: FedEx / UPS / DHL Worldwide

Suffix Tree Information

• Model: VI702
  • Replaces V1701 Vnet/IP Interface Card
  • Supports PCI Express x1–x16 installation
  • Complies with PCIe CEM Spec 1.0a, 2.5 GT/s

Technical Specifications

• Communication Speed: 1 Gbps Full Duplex
• Transmission Standard: 1000BASE-T
• Network Cable: CAT5e UTP (Enhanced Category 5)
• Connector Type: RJ45 Female
• Max Transmission Distance: 100 m (to Layer 2 switch)
• Power Supply: 3.3 V ±9%
• Current Consumption: Max. 2.5 A
• Weight: Approx. 0.18 kg

Performance Features

• Stable high-speed communication up to 1 Gbps
• Compatible with PCIe x1 to x16 slots
• Supports full-duplex data transfer with low latency
• Lightweight design (0.18 kg) for easy installation
• LED diagnostics for quick status monitoring

Diagnostic Indicators

• RDY Lamp: Lights when card is normal
• RCV Lamp: Lights on signal detection
• SND Lamp: Lights during signal transmission

Extended Technical Details

• Operating Temperature: 0°C to +60°C
• Storage Temperature: -20°C to +85°C
• Vibration Resistance: 5–150 Hz, 0.15 mm amplitude
• Electrostatic Immunity: ±15 kV air discharge
• Communication Error Rate: Less than 10⁻⁹
• Noise Tolerance: 10 V/m RF Immunity
• Interface Compatibility: Yokogawa Vnet/IP network systems

Key Advantages

• Fast 1 Gbps full-duplex industrial communication
• Reliable data flow with minimal interference
• Compact PCIe design, fits multiple slots
• Built-in status lamps simplify troubleshooting
• Ideal for upgrading legacy V1701 systems

Applications

• Distributed Control Systems (DCS)
• Industrial automation networks
• Process monitoring and control
• Oil, gas, and energy system integration

Packaging & Shipping

• Factory original packing
• Ships via FedEx, UPS, or DHL
• Global express delivery available
• Includes full documentation and warranty card

FAQ

• Q: What is the maximum transmission speed?
  A: It supports up to 1 Gbps full-duplex transfer.
• Q: Can I use the VI702 in a PCI slot?
  A: No, it is designed for PCI Express slots only.
• Q: Does it support CAT6 cables?
  A: Yes, but CAT5e UTP is the standard cable recommended.
• Q: What does the RDY light mean?
  A: It indicates that the card is operating normally.
• Q: How can I order replacements?
  A: Contact our sales team for availability and pricing.
