Yaskawa SGDB-10ADG Servo Amplifier | Vector Control Drive

Yaskawa SGDB-10ADG Servo Amplifier Overview

• The Yaskawa SGDB-10ADG gives steady motor control.
• It works with simple setup and fast start.
• It fits many drive tasks that need smooth moves.
• Author: Powergear X Automation

Main Highlights

• Fast vector control for clean motion.
• Strong build for long service time.
• Stable output at 230 VAC.
• Safe work with built-in trip functions.
• Low noise during long runs.

Technical Details

• Model: SGDB-10ADG
• Brand: Yaskawa
• Part of the Sigma Series
• Input range: 200–230 VAC
• Input current: 8 A max
• Output: 230 VAC, 7 A
• Frequency: 50/60 Hz
• Phase: 3-phase
• Control: Vector control
• Cooling: Natural air flow
• Heat load: 110 W typical
• Response time: under 1 ms
• Operating range: 0°C to 40°C
• Rated altitude: up to 1000 m
• Size: 10.2 in × 6.1 in × 3.9 in
• Weight: 6.00 lbs (2.72 kg)
• Shield level: basic surge protection
• Drive type: precision servo work

Why This Unit Performs Well

• Holds torque steady during fast moves.
• Gives smooth low-speed action.
• Reduces overshoot by sharp control loops.
• Easy mount for small cabinets.
• Low heat makes it simple to maintain.

Warranty and Support

• Includes a 12-month warranty.
• Email: sales@powergearx.com
• Phone: +86 18030005825

Shipping Choices

• FedEx International
• UPS Express
• DHL Worldwide

Typical Uses

• Pick-and-place machines
• Small CNC platforms
• Sliding stages with fine motion
• Light robots and handlers
• Speed control in small systems

User Notes

• Keep airflow paths open.
• Check wiring torque often.
• Confirm ground before run.
• Use shielded signal lines.
• Allow space for heat release.

FAQ

What setup step helps most during first use?

• Check motor parameters before enabling output.

How can I improve stability in slow motion?

• Use short cables and adjust gain values lightly.

What should I do if the drive trips during load?

• Reduce load spikes and check brake release timing.

Is the SGDB-10ADG fine for long run cycles?

• Yes, but keep vents clean to hold cool temperature.

How do I detect aging parts early?

• Watch for small speed lag and rising heat.
