Vibro-Meter CP 216 Pressure Transducer 143-216-000-131 | High Temp Sensor

Vibro-Meter CP 216 Piezoelectric Pressure Transducer | 143-216-000-131

• Brand: Vibro-Meter®
• Model: CP 216
• Type: Piezoelectric pressure transducer with high-temperature connector
• Ordering Number: 143-216-000-131
• Warranty: 12 months standard warranty

The Vibro-Meter CP 216 offers strong performance in extreme heat and pressure. It measures fast pressure changes up to 15 kHz with high precision. Built for turbines and high-temperature testing, this sensor delivers reliability when ordinary devices fail.

Technical Data

• Dynamic Range: 0.0005–250 bar (0.007–3626 psi)
• Overload Spike Limit: Up to 350 bar (5076 psi)
• Linearity: ±1% over the entire range
• Acceleration Sensitivity: ≤ 0.5 pC/g (0.0025 bar/g)
• Resonant Frequency: > 80 kHz
• Insulation Resistance: >10⁹ Ω at 23°C, >5×10⁴ Ω at 450°C
• Capacitance: 320 pF (sensor) + 200 pF/m (cable)
• Cable Weight: 25 g/m | Sensor Weight: 12 g
• Shock Resistance: Up to 2000 g (1 ms pulse)

Temperature and Connector Options

• Transducer: Continuous −54 to 470°C, Extreme −70 to 520°C
• Connector: Vibro-Meter high-temp type rated to 650°C
• Cable: Mineral insulated twin conductor type

Ordering Configuration Tree

• CP 216 Series
  • – High-Temperature Connector: −70°C to 650°C
  • – Cable Length Options: 1 m (default), 2 m, 5 m, custom lengths
  • – Ordering Example: 143-216-000-131 = CP 216 with high-temp connector, 1 m cable

Package Includes

• 1 × Vibro-Meter CP 216 transducer (model 143-216-000-131)
• 1 × High-temperature connector pre-attached
• 1 × Mounting and setup guide
• Secure shock-protected packaging
• Worldwide shipping via FedEx, UPS, or DHL

FAQ

• Q: Can I use CP 216 in a gas turbine with exhaust over 500°C?
  A: Yes, it operates safely up to 520°C with stable output.
• Q: Does it require external power?
  A: No, the CP 216 is a self-generating piezoelectric device.
• Q: What type of signal does it output?
  A: It delivers a charge signal that connects to a charge amplifier or converter.
• Q: How long is the calibration valid?
  A: Factory calibration remains valid for its lifetime under normal use.
• Q: Is this sensor compatible with other IPC signal conditioners?
  A: Yes, it fully supports IPC 704 and similar conditioning modules.

Contact Information

• Email: sales@powergearx.com
• WhatsApp: +86 18030005825
• For custom lengths or volume orders, please reach our sales team.
