Product details
VAEM-L1-S-8-PT | Festo Valve Control Module for 8 Solenoid Valves
The Festo VAEM-L1-S-8-PT is a high-performance valve control module. It precisely actuates up to 8 solenoid valves. The PT interface allows flexible integration into modular valve terminals. It supports compact, decentralized automation. This module is ideal for efficient control systems.
- Controls up to 8 solenoid valves with reliable digital signals.
- PT (parallel transmission) electrical interface for fast, simple wiring.
- Compact design for cabinet or field installation.
- Plug-and-play with Festo VAEM and VTUG platforms.
- LED indicators show channel status at a glance.
Technical Data
- Brand: Festo
- Model: VAEM-L1-S-8-PT
- Part Number: VAEM-L1-S-8-PT
- Series: VAEM
- Module Type: Valve control module
- Number of Outputs: 8 solenoid channels
- Interface Type: PT (Parallel Transmission)
- Operating Voltage: 24 V DC (typical)
- Output Type: Digital, short-circuit protected
- Mounting: DIN rail or valve terminal integration
- Ambient Temperature: 0 °C to +50 °C
- Protection Class: IP20 (IP65 with appropriate housing)
- Status Indicators: LED per output channel
- Product Weight: 49 g
- Electrical Interface: VAEM-L1-S-8-PT
- Corrosion Resistance Class CRC: 2 – Moderate corrosion stress
- LABS (PWIS) Conformity: VDMA24364-B1/B2-L
- Note on Materials: RoHS compliant
Measurement & Performance
- Measurement Range: Not applicable (digital control module)
- Frequency Response: Not specified (digital switching)
- Sensitivity: Not applicable
- Linearity: Not applicable
- Resolution: 1 bit per channel (on/off)
- Temperature Range: 0 °C to +50 °C
- Environmental Resistance: Moderate corrosion stress (CRC 2)
- Interference Immunity: Designed for industrial environments
Certifications & Approvals
- KC Mark: KC-EMV
- Approval: RCM
- c UL us – Recognised (Oil)
- RoHS compliant
Installation Guide
- Mount on DIN rail or integrate into a valve terminal.
- Connect the PT interface to the control system.
- Wire up to 8 solenoid valves to the output channels.
- Apply 24 V DC operating voltage.
- Check LED indicators for each channel status.
- Ensure IP20 protection. Use a housing for IP65.
Commissioning & Maintenance
- No special tools needed for plug-and-play setup.
- LEDs simplify troubleshooting and status checks.
- Short-circuit protection reduces downtime.
- Keep the module clean and dry.
- No regular maintenance required under normal use.
Compatibility
- Works with Festo VAEM and VTUG platforms.
- Integrates into modular valve terminals.
- Supports decentralized automation architectures.
- Compatible with standard 24 V DC control systems.
Expert Review
The VAEM-L1-S-8-PT stands out for its compact size and simple PT interface. It controls 8 valves with minimal wiring. LED indicators speed up diagnostics. This module suits OEMs and system integrators who need reliable, space-saving valve control. The moderate corrosion resistance fits most factory environments. For harsh conditions, add a protective housing.
Manager’s Insight
This module cuts installation time. The PT interface removes complex wiring. It is a smart choice for modular machines. Customers often pair it with Festo VTUG terminals. The 49 g weight and DIN rail mount save cabinet space. Order this part for fast delivery from our warehouse.
Ideal Applications & Equipment
- Modular valve terminals
- Decentralized automation systems
- Machine tools
- Packaging equipment
- Assembly lines
- Process control cabinets
- Festo VAEM and VTUG platforms
Frequently Asked Questions (FAQ)
Q: How many valves can this module control?
A: It controls up to 8 solenoid valves.
Q: What is the PT interface?
A: PT means Parallel Transmission. It sends digital signals to each valve channel.
Q: What voltage does it need?
A: It typically uses 24 V DC.
Q: Is it protected against short circuits?
A: Yes, the digital outputs are short-circuit protected.
Q: Can I use it outdoors?
A: No, the standard protection is IP20. Use a proper housing for IP65.
Q: What is the ambient temperature range?
A: It works from 0 °C to +50 °C.
Q: Does it come with LEDs?
A: Yes, each output channel has an LED indicator.
Q: What certifications does it hold?
A: It has KC-EMV, RCM, c UL us – Recognised (Oil), and RoHS compliance.
Q: How do I mount it?
A: Use a DIN rail or integrate it into a valve terminal.
Q: What is the product weight?
A: It weighs 49 g.
Q: Is it RoHS compliant?
A: Yes, it is RoHS compliant.
Q: What is the corrosion resistance class?
A: CRC 2 – Moderate corrosion stress.
Q: Does it work with Festo VTUG?
A: Yes, it is suitable for VAEM and VTUG platforms.
Q: How fast can I get this part?
A: We ship in 12-24 hours via FedEx, UPS, or DHL.
Q: What is the warranty?
A: We offer a 12-month warranty.
Q: What is in the package?
A: The package includes the VAEM-L1-S-8-PT module. Please check for any accessories.
Q: Can I use it with non-Festo valves?
A: It works best with Festo systems. Check voltage and signal compatibility first.
Q: Do I need special software?
A: No, it uses simple digital signals. No special software is required.
Buying Guide
- Check your valve count. This module handles 8 channels.
- Confirm your control voltage is 24 V DC.
- Verify the PT interface matches your controller.
- For washdown areas, add an IP65 housing.
- Order spare modules for critical lines.
- Pair with Festo VAEM or VTUG terminals for best fit.
Package Contents & Warranty
- 1x Festo VAEM-L1-S-8-PT module
- 12-month warranty from date of purchase
- Shipping: 12-24 hours via FedEx, UPS, or DHL
- No extra accessories included unless specified
