TWDDDI8DT Schneider Electric 8-Input Digital Module | Twido PLC

Product Brief

• TWDAMM6HT is a compact analog I/O module from Schneider Electric Twido series.
• It offers 4 inputs and 2 outputs for voltage (0–10V) or current (4–20 mA) signals.
• Ideal for small to mid-size PLC systems that need analog signal handling.
• Easy to install with removable screw terminal blocks.
• Provides reliable performance for industrial automation tasks.

Technical Specifications

• Brand: Schneider Electric
• Model: TWDAMM6HT
• Series: Twido
• Type: Analog I/O module
• Inputs: 4 channels (voltage 0–10 V or current 4–20 mA)
• Outputs: 2 channels (voltage 0–10 V or current 4–20 mA)
• Resolution: 12 bits for both inputs and outputs
• Supply voltage: 24 V DC (range 20.4…28.8 V)
• Current consumption: 60 mA at 5 V DC, 80 mA at 24 V DC
• LSB values: 2.5 mV (voltage), 4.8 µA (current)
• Input impedance: ≤250 Ω (current), ≥10 kΩ (voltage)
• Output load: ≤300 Ω (current), ≥2 kΩ (voltage)
• Conversion time: 20 ms + 1 PLC cycle
• Stabilization time: 20 ms
• Measurement error (25 °C): ±0.5% FS (voltage/current)
• Repeat accuracy: ±0.5% FS
• Non-linearity: ±0.4% FS (input), ±0.5% FS (output)
• Total error: ±1% FS (input), ±2% FS (output)
• Temperature coefficient: ±0.06% FS/°C (input), ±0.5% FS/°C (output)
• Common mode rejection: 50 dB
• Cable type: Shielded twisted pair recommended
• Insulation: Photocoupler between channels and logic

Key Performance Indicators

• Range: 0–10 V or 4–20 mA – covers standard industrial signals.
• Resolution: 12 bits – gives fine detection of signal changes.
• Accuracy: ±0.5% FS at 25 °C – reliable for process control.
• Linearity: ±0.4% FS – ensures consistent output.
• Temperature range: 0…55 °C operation, -25…70 °C storage.
• Environmental: IP20 protection, suitable for clean panels.
• Immunity: 50 dB common mode rejection reduces noise.

Installation & Setup

• Mount the module in a Twido base or rack.
• Use shielded twisted pair cables for analog signals.
• Connect the removable screw terminal block for I/O wiring.
• Supply external 24 V DC (20.4…28.8 V) to the module.
• Set jumpers (if any) to select voltage or current mode.

Compatibility & Integration

• Works with all Twido PLC controllers (TWDLMDA etc.).
• Also compatible with Modbus networks via the main controller.
• Supports both sink and source wiring conventions.

Typical Applications & Equipment

• Process monitoring: temperature, pressure, flow transmitters.
• Motor control: speed feedback from analog drives.
• HVAC systems: damper and valve position control.
• Packaging machines: fill level and tension control.
• Small conveyors and material handling systems.

Expert Review

• “The TWDAMM6HT is a workhorse for small analog tasks. The 12‑bit resolution and fast conversion make it great for real‑time control. The removable terminals speed up wiring. We use it in many compact panels.”
• – Senior Controls Engineer, Powergear X

Manager’s Insight

• “For cost‑effective analog expansion, this module delivers. It matches Twido’s reliability. Always check the output load range – staying within 300 Ω (current) or above 2 kΩ (voltage) ensures stable performance.”
• – Product Manager, Powergear X

Certifications & Standards

• CE marked – meets European safety and EMC standards.
• UL and CSA certified – for North American installations.
• IP20 protection – suitable for control cabinet mounting.
• Dielectric strength: 800 V between I/O and supply.

Package Contents

• 1x TWDAMM6HT analog I/O module.
• 1x removable screw terminal block.
• Quick start guide (English).
• No additional software – works with TwidoSoft or EcoStruxure Machine Expert.

Warranty & Shipping

• Warranty: 12 months from date of purchase.
• Dispatch: 12–24 hours after order confirmation.
• Carriers: FedEx, UPS, DHL – tracking number provided.

Frequently Asked Questions

• What cable should I use?
  Use shielded twisted pair cable to reduce electrical noise.
• Can I mix voltage and current on the same module?
  Yes, each channel is individually configurable.
• How do I set the input type?
  You configure it via the PLC software (TwidoSoft) – no hardware jumpers for this model.
• What is the maximum load on the output?
  For current output: ≤300 Ω. For voltage output: ≥2 kΩ.
• Is this module hot‑swappable?
  No – power down the PLC before removing or inserting the module.
• What is the effect of temperature on accuracy?
  Input drifts 0.06% FS/°C, output drifts 0.5% FS/°C – keep the panel cool for best results.

Selection Guide

• Count the analog signals in your system – choose TWDAMM6HT if you need 4 inputs and 2 outputs.
• If you need more channels, consider adding additional modules.
• For high‑accuracy applications, use a separate power supply for the analog circuits.
• Always verify the output load before wiring to avoid signal distortion.
