TSXASZ401 Schneider Electric Modicon TSX Micro Analog Output Module 4 Channels

TSXASZ401 Schneider Electric Modicon TSX Micro Analog Output Module

The TSXASZ401 is an analog output module for the Modicon TSX Micro platform. It gives you 4 output channels in one compact unit. The module supports 0–10 V and +/- 10 V signals. It reacts in just 400 µs. That speed suits fast control loops. The unit also protects against short circuits. Isolation reaches 1000 V AC. This helps block electrical noise. The module follows RoHS rules. It weighs only 0.2 kg. So it saves panel space and reduces load.

Technical Data

• Brand: Schneider Electric
• Model: TSXASZ401
• Series: Modicon TSX Micro automation platform
• Type: Analog output module
• Part Number: TSXASZ401
• EAN: 3389110604535
• Channels: 4
• Output Type: 0–10 V, +/- 10 V
• Response Time: 400 µs
• Output Load: 2 Ohms or more
• Conversion: 11 bits (0–10 V), 11 bits + sign (+/- 10 V)
• Protection: Short-circuit
• Temperature Drift: 0.096 % per 10 °C
• Current Use: 90 mA
• Isolation Voltage: 1000 V AC
• Compliance: RoHS
• Green Premium: Not a Green Premium product
• Net Weight: 0.2 kg
• Shipping Weight: 1.00 lbs (0.45 kg)

Packing Details

• Unit type: PCE
• Units in package 1: 1
• Package 1 height: 5.5 cm
• Package 1 width: 18.0 cm
• Package 1 length: 26.0 cm
• Package 1 weight: 636.0 g

Expert Review

The TSXASZ401 is a smart pick for tight control jobs. Four channels save rack space. The 400 µs response helps fast loops. The 11-bit resolution gives smooth signals. The 1000 V AC isolation adds safety. The 2 Ohm load support fits many drives. The module is light and easy to mount. For small to mid-size systems, this unit offers strong value.

Manager’s Insight

Buyers want fast shipping and low risk. The TSXASZ401 meets both needs. It ships in 12–24 hours. It carries a 12-month warranty. Couriers include Fedex, UPS, and DHL. The module works with common TSX Micro racks. So setup is quick. For teams that need reliable analog output, this model is a safe choice. Reach us at sales@powergearx.com or +86 18030005825 for stock and price.

Best Fit Devices and Applications

• Servo and drive control
• Valve and damper positioning
• Speed and flow control
• Process signal output
• Test and measurement benches
• Packaging and labeling machines
• Small motion control panels
• Retrofit of TSX Micro systems

FAQ

What makes this module fast?

It has a 400 µs response time. That speed helps quick control loops.

How many signals can it send?

It sends up to 4 analog signals at once.

Which output ranges does it offer?

It offers 0–10 V and +/- 10 V ranges.

What is the smallest load it drives?

It drives loads of 2 Ohms or higher.

Does it protect against wiring faults?

Yes. It has short-circuit protection built in.

How stable is the signal over temperature?

Drift stays at 0.096 % for every 10 °C change.

What isolation level does it provide?

It provides 1000 V AC isolation. This helps cut electrical noise.

Is it RoHS compliant?

Yes. It follows RoHS rules.

Is it a Green Premium product?

No. It is not a Green Premium product.

How much current does it draw?

It draws 90 mA.

How heavy is the module?

Net weight is 0.2 kg. Shipping weight is about 0.45 kg.

How fast do you ship?

We dispatch in 12–24 hours.

Which couriers do you use?

We use Fedex, UPS, and DHL.

What warranty do you offer?

We offer a 12-month warranty.

How do I pick the right analog module?

Check your channel count and signal range first. Match them with the TSXASZ401 specs. Then confirm load and isolation needs. Ask our team at sales@powergearx.com for help.

Can it replace older TSX Micro analog cards?

In many cases, yes. Check rack type, wiring, and signal range first. The TSXASZ401 fits many legacy setups.

What should I check before power-on?

Check wiring, load size, and grounding. Make sure the load is at least 2 Ohms.

How do I keep it running well?

Keep it clean and dry. Check cables often. Stay within the rated current and load range.

Where can I buy genuine stock?

Contact sales@powergearx.com or +86 18030005825. We confirm stock, price, and shipping fast.
