Name: TSXAMZ600 Schneider Modicon TSX Micro Analog I/O Module 4 In 2 Out
SKU: TSXAMZ600
Price: 234.00 USD
Availability: InStock

Product details

TSXAMZ600 Schneider Electric Modicon TSX Micro Analog I/O Module

The TSXAMZ600 is a versatile analog I/O module from Schneider Electric. It belongs to the Modicon TSX Micro automation platform. Moreover, it packs 4 analog inputs and 2 analog outputs into one compact unit. This module handles both current and voltage signals with high precision. As a result, it suits many demanding industrial environments. In addition, the TSXAMZ600 delivers reliable performance for control and monitoring tasks.

Why This Module Stands Out

First, the TSXAMZ600 supports 4…20 mA, 0…20 mA, ±10 V, and 0…10 V signals. Therefore, you need fewer signal converters. Second, it offers 11-bit resolution for smooth data. Third, the 400 µs response time fits fast control loops. Consequently, this module works well in mixed-signal applications. Finally, it saves panel space and wiring time.

Technical Specifications

Brand: Schneider Electric
Model: TSXAMZ600
Series: Modicon TSX Micro automation platform
Module Type: Analog I/O module
Channels: 4 inputs, 2 outputs
Analog Input Types: 4…20 mA, 0…20 mA, ±10 V, 0…10 V
Analog Output Types: 4…20 mA, 0…20 mA, 0…10 V, ±10 V
Resolution: 11 bits (0…10 V, 0…20 mA, 4…20 mA); 11 bits + sign (±10 V)
Measurement Range: 0…20 mA, 4…20 mA, 0…10 V, ±10 V
Acquisition Period: 16 ms (current or voltage)
Response Time: 400 µs
Output Load: 0.6 Ohm (current); ≥ 2 Ohm (voltage)
Protection: Short-circuit (voltage outputs); short-circuit (current outputs)
Temperature Drift: 0.107 %/10 °C (current); 0.083 %/10 °C (voltage)
Input Impedance: 250 Ohm (current); 2.2 Ohm (voltage)
Current Consumption: 180 mA
Isolation Voltage: 1000 V AC
Product Weight: 0.53 lb (0.24 kg)
GTIN: 00785901344476
Country of Origin: FR

Installation Guide

First, mount the module on a standard TSX Micro rack. Then connect input and output wires per the wiring diagram. Also, use shielded cables for analog signals. Moreover, keep signal wires away from power lines. After that, verify isolation voltage before powering up. Finally, check that short-circuit protection is active.

Commissioning and Maintenance

To begin, calibrate inputs and outputs at startup. Then monitor temperature drift in extreme conditions. Also, clean terminals regularly to avoid resistance. If isolation fails, replace the module. Furthermore, use the 18-month warranty for peace of mind.

Compatibility Notes

The TSXAMZ600 works with Modicon TSX Micro PLCs. In addition, it is compatible with PL7 Micro software. It also fits standard TSX Micro racks. Moreover, it supports 4…20 mA and 0…10 V sensors. Finally, it drives actuators with 0…20 mA or ±10 V.

Certifications and Compliance

The EU RoHS Directive is not applicable because this product is out of legal scope. However, China RoHS declaration is available. For WEEE, dispose via proper EU collection. Also, the product must not go into rubbish bins.

Package Contents

1 x TSXAMZ600 analog I/O module
1 x Product datasheet
1 x Wiring diagram
18-month warranty card

Warranty and Shipping

Therefore, you get an 18-month warranty. We dispatch in 12–24 hours after order. In addition, we use FedEx, UPS, and DHL. For help, contact sales@powergearx.com or +86 18030005825 (WhatsApp).

Expert Review

The TSXAMZ600 stands out for its dual signal support. It reads 4…20 mA and ±10 V without extra hardware. Moreover, the 11-bit resolution gives smooth data. The 400 µs response time fits fast control loops. Also, temperature drift stays low. As a result, this module is a solid choice for mixed-signal applications. It saves panel space and wiring time. For system integrators, the TSXAMZ600 reduces inventory needs. One module covers both current and voltage tasks.

Manager’s Insight

We see strong demand for analog modules that handle both current and voltage. The TSXAMZ600 meets that need. Its 4 input and 2 output layout balances cost and function. Moreover, the 18-month warranty and fast shipping make it easy to stock. For legacy TSX Micro systems, this module extends service life. It avoids full platform migration. Consequently, that saves money and downtime. Our team recommends keeping a few units on hand.

Best Applications and Equipment

Modicon TSX Micro PLC systems
Process control loops
Flow, pressure, and temperature monitoring
Valve and actuator positioning
Data acquisition panels
Legacy automation upgrades
Test benches and lab equipment

FAQ

Q: What makes the TSXAMZ600 different from other analog modules?

A: It combines 4 inputs and 2 outputs. It also accepts both current and voltage signals. Therefore, that cuts the need for extra signal converters.

Q: Can I use the TSXAMZ600 with a non-Schneider PLC?

A: It is designed for the Modicon TSX Micro platform. However, using it with other PLCs may need adapters. Always check voltage and signal compatibility first.

Q: How often should I calibrate this module?

A: For most industrial sites, calibrate once a year. In harsh areas with high temperature swings, calibrate every six months. The low temperature drift helps keep accuracy between calibrations.

Q: What is the typical lead time for shipping?

A: We dispatch in 12 to 24 hours. We use FedEx, UPS, or DHL. You get tracking information right after shipment. For urgent needs, contact us via WhatsApp at +86 18030005825.

Q: Is the TSXAMZ600 still available even though it is non-stock?

A: Yes. “Non-stock” means we do not keep it on the shelf. But we source it fast from our network. As a result, most orders ship within one business day. Email sales@powergearx.com to confirm current availability.

Q: What should I check before buying this module?

A: First, confirm your PLC series is Modicon TSX Micro. Second, list your sensor signals (current or voltage). Third, check your rack has space. Fourth, verify your power budget can handle 180 mA. Fifth, decide if you need the 18-month warranty. If all match, the TSXAMZ600 is a safe pick.

Q: How do I handle wiring for best noise immunity?

A: Use twisted-pair shielded cables. Ground the shield at one end only. Route analog wires away from AC drives and relays. Keep cable runs short. Consequently, these steps boost noise rejection and protect signal integrity.

Q: Does this module support hot-swapping?

A: No. Always power down the rack before you remove or insert the TSXAMZ600. Hot-swapping can damage the module and the PLC. Therefore, follow standard safety lockout procedures.

Q: What if I need more than 4 inputs?

A: You can add another TSXAMZ600 module. The TSX Micro platform supports multiple analog modules. Just check your rack power and slot count. For large channel counts, consider a higher-density module from the same series.

Q: Can I get a bulk discount for multiple units?

A: Yes. Contact sales@powergearx.com with your target quantity. We offer tiered pricing for system integrators and OEMs. Fast shipping via FedEx, UPS, or DHL is available for bulk orders too.
