TSXAEY1600 Modicon Premium Analog Input Module by Schneider Electric
The TSXAEY1600 is a 16-channel high level analog input module from the Schneider Electric Modicon Premium series. It handles voltage and current signals with 12-bit resolution. This module occupies one slot and uses the backplane 5 V DC supply. It suits industrial control systems that need reliable multi-channel data acquisition. The product is discontinued. Last verified in September 2026. For expert support, contact sales@powergearx.com or +86 18030005825.
Technical Data
- Brand: Schneider Electric
- Model: TSXAEY1600
- Series: Modicon Premium
- Module type: Analog input, high level
- Channels: 16
- Signal type: High level voltage / current
- Measurement range: High level voltage and current
- Resolution: 12 bits
- Accuracy: Not available
- Isolation: Not available
- Diagnostics: Not available
- Conversion time: Not available
- Frequency response: Not specified
- Sensitivity: Not specified
- Linearity: Not specified
- Temperature range: Not available for operating and storage
- Relative humidity: Not available
- Environmental resistance: IP20 protection rating
- Noise immunity: Not specified
- Slots required: 1
- Supply voltage: 5 V DC (backplane)
- Bus current: 270 mA at 5 V DC
- Power consumption: 1.35 W
- Dimensions (H×W×D): 140 × 35 × 80 mm
- Weight: 0.3 kg
- Lifecycle: Discontinued (Last verified: 2026-09)
Installation Guide
- Mount the module in one free slot of a Modicon Premium backplane.
- Ensure the backplane provides 5 V DC with at least 270 mA available.
- Connect high level voltage or current signals to the 16 input channels.
- Respect IP20 environment. Avoid dust and moisture.
- For wiring details, refer to the original Schneider Electric manual.
Commissioning and Maintenance Ease
- No special diagnostics are available on this module.
- Check power consumption and backplane load before startup.
- Use standard Modicon Premium configuration tools.
- Replace only with an identical or compatible module.
- Keep spare units in a dry, temperature-controlled area.
Compatibility Notes
- Works with Modicon Premium PLC racks and backplanes.
- Compatible with 5 V DC backplane power only.
- Not compatible with other PLC families without adapters.
- Designed for high level analog signals, not low level sensors.
Certifications
- No specific certifications listed for this discontinued module.
- Original Schneider Electric product. Check local standards.
- For compliance questions, email sales@powergearx.com.
Packing List
- 1 × TSXAEY1600 analog input module
- 1 × protective shipping box
- Documentation not included unless stated.
Warranty and Shipping
- Warranty: 12 months from delivery.
- Dispatch time: 12 to 24 hours after payment.
- Carriers: FedEx, UPS, DHL.
- Tracking number provided after shipment.
- For urgent orders, call or WhatsApp +86 18030005825.
Expert Review
The TSXAEY1600 was a solid 16-channel analog input module for its time. It offered 12-bit resolution and a compact one-slot design. However, it lacks diagnostics, isolation, and detailed environmental specs. The module is now discontinued. Buyers should verify stock and compatibility. For legacy Modicon Premium systems, it remains a practical spare part. The 5 V DC backplane supply and 270 mA current draw are modest. Weight is only 0.3 kg, so shipping is simple. If you need high channel density in a discontinued platform, this module is a reasonable choice. For new designs, consider newer Schneider Electric alternatives. Contact sales@powergearx.com for a manager’s insight on stock and pricing.
Manager’s Insight
We see steady demand for the TSXAEY1600 from maintenance teams keeping older Modicon Premium lines alive. The 16-channel count saves space. But the lack of isolation and diagnostics means you must design your system carefully. The 12-bit resolution is adequate for many process signals. Stock is limited because the product is discontinued. Order soon if you need a spare. We ship within 12 to 24 hours via FedEx, UPS, or DHL. For bulk inquiries, email sales@powergearx.com or WhatsApp +86 18030005825.
Best Devices and Applications
- Modicon Premium PLC systems in factory automation.
- Process control with voltage or current loop signals.
- Legacy machinery that needs 16 analog inputs.
- Data acquisition for slow to medium speed signals.
- Not for high precision or isolated channel requirements.
FAQ
Q: What is the resolution of the TSXAEY1600?
A: The module provides 12-bit resolution for high level voltage and current signals.
Q: Does this module have channel isolation?
A: No. The specification sheet lists isolation as not available.
Q: Can I use this module with a different PLC brand?
A: It is designed for Modicon Premium racks. Other brands may need adapters or may not work.
Q: How many slots does it take?
A: One slot only. The dimensions are 140 × 35 × 80 mm.
Q: What is the power consumption?
A: It draws 270 mA at 5 V DC, which equals 1.35 W.
Q: Is the TSXAEY1600 still available?
A: It is discontinued. Last verified in September 2026. Check with us for current stock.
Q: What is the warranty and shipping time?
A: We offer a 12-month warranty. Ships in 12 to 24 hours via FedEx, UPS, or DHL.
Q: Do you provide technical support for legacy modules?
A: Yes. Email sales@powergearx.com or WhatsApp +86 18030005825 for help.
Q: What should I check before buying a discontinued module?
A: Confirm your backplane voltage, current budget, and signal type. Also verify physical slot space.
Q: Can I return the module if it does not fit?
A: Contact us first. Returns are subject to our policy. The 12-month warranty covers defects only.
Buying Guide
- Check your Modicon Premium rack has a free slot and 5 V DC power.
- Confirm your sensors output high level voltage or current.
- Decide if 12-bit resolution meets your accuracy needs.
- Plan for no isolation and no diagnostics in your design.
- Order spare units because the product is discontinued.
- Use FedEx, UPS, or DHL for fast delivery.
- For bulk or urgent needs, contact sales@powergearx.com or +86 18030005825.
