Name: TM5SPS2 Schneider Modicon TM5 I/O Power Module 24 Vdc for M241 M258
SKU: TM5SPS2
Price: 234.00 USD
Availability: InStock

Product details

TM5SPS2 Schneider Electric Modicon TM5 Power Distribution Module

TM5SPS2 is a power distribution module from Schneider Electric. Moreover, it belongs to the Modicon TM5 series. This module supplies 24 Vdc power to an I/O segment. In addition, it feeds the TM5 bus. As a result, it delivers up to 10 A per segment. The module also suits compact and distributed control systems. Furthermore, it works with Modicon M241, M251, M258, and LMC058 platforms. Therefore, the design saves panel space. The module is IP20 rated. Meanwhile, it remains active in the lifecycle. Last verification was 2026-09.

Why This Module Stands Out

Clean power distribution: One module feeds a full I/O segment.
High current capacity: 10 A output supports demanding loads.
Clear diagnostics: LEDs show ModuleOK, DcOk, and segment fuse OK.
Wide input range: It accepts 20.4–28.8 Vdc.
Low self-consumption: The module draws only 25 mA.
Compact body: It measures 99 × 25 × 75 mm.
Light weight: It weighs just 0.05 kg.

Technical Data

Brand: Schneider Electric
Model: TM5SPS2
Series: Modicon TM5
Module type: Power distribution (I/O power segment + TM5 bus supply)
Channels: Not applicable
Signal type: Not applicable
Input range: 20.4–28.8 Vdc
Resolution: Not applicable
Accuracy: Not applicable
Isolation: Not applicable
Diagnostics: ModuleOK, DcOk, segment fuse OK
Response time: Not applicable
Supply voltage: 24 Vdc nominal
Power consumption: 25 mA for the module itself
Bus current: Max 10 A output per segment
Maximum output current: 10 A
Operating temperature: 0…+55 °C
Storage temperature: -25…+70 °C
Protection rating: IP20
Dimensions (H×W×D): 99 × 25 × 75 mm
Weight: 0.05 kg

Installation Guide

First, mount the module on a TM5 bus base.
Also, keep the cabinet clean and dry.
Then, use 24 Vdc supply wiring with correct gauge.
In addition, respect the 10 A segment limit.
Next, check polarity before power-up.
Moreover, leave space for airflow.
Finally, follow local electrical codes.
After that, torque terminals to maker specs.

Setup and Maintenance Convenience

Three LEDs speed up fault finding.
For example, the segment fuse OK LED shows fuse state.
Likewise, DcOk confirms 24 Vdc presence.
In addition, ModuleOK shows module health.
Therefore, you can replace fuses without removing wiring.
Also, compact size eases service access.
As a result, no special tools are needed for checks.

Compatibility Notes

It works with Modicon M241.
It also works with Modicon M251.
Furthermore, it works with Modicon M258.
In addition, it works with Modicon LMC058.
Moreover, it fits the Modicon TM5 distributed I/O platform.
Finally, it is also used with M340 and M580 systems.

Expert Review

The TM5SPS2 solves a common panel problem. For instance, it sends clean 24 Vdc power to one I/O segment. In addition, it feeds the TM5 bus. The 10 A rating gives headroom for many I/O slices. Moreover, the three LEDs make troubleshooting fast. The 25 mA self-draw is low. Furthermore, the IP20 body fits tight cabinets. The wide 20.4–28.8 Vdc range handles supply drift. As a result, machine builders reduce wiring time. It also lowers downtime risk. However, the main limit is the 10 A segment cap. Therefore, plan loads with margin.

Manager’s Insight

- Buy this module when a segment needs its own fused supply.
- Also, stock spare fuses for faster service.
- Moreover, use one module per segment to isolate faults.

In addition, keep spare units on hand for critical lines.
Furthermore, pair with Modicon M241 or M258 for compact builds.
Therefore, check total segment current before adding slices.
Finally, the active lifecycle status supports long-term planning.

Best-Fit Equipment and Applications

Certifications and Compliance

Packing List

1 × TM5SPS2 module
1 × quick start guide
1 × factory test report
Protective carton
Anti-static bag

Warranty and Shipping

12-month warranty on the module.
Orders ship in 12–24 hours.
Express options include FedEx, UPS, and DHL.
Tracking number sent after dispatch.
Packed for safe transport.

FAQ

Q: What does the TM5SPS2 do?
A: It sends 24 Vdc power to one TM5 I/O segment. It also supplies the TM5 bus.
Q: How much current can one segment take?
A: The module supports up to 10 A per segment.
Q: Which controllers work with it?
A: It works with Modicon M241, M251, M258, and LMC058. It also fits M340 and M580 TM5 setups.
Q: What do the LEDs mean?
A: ModuleOK shows module health. DcOk shows 24 Vdc input. Segment fuse OK shows fuse status.
Q: Does it need a separate power supply?
A: Yes. Feed it with a 24 Vdc source within 20.4–28.8 Vdc.
Q: Can I replace the fuse in the field?
A: Yes. The fuse is serviceable. Always isolate power first.
Q: How much space does it need?
A: The body is 99 × 25 × 75 mm. Leave room for airflow.
Q: What is the operating temperature?
A: It runs from 0…+55 °C.
Q: What is the protection rating?
A: The module is IP20 rated. Keep it inside a clean cabinet.
Q: How fast do orders ship?
A: We ship in 12–24 hours via FedEx, UPS, or DHL.
Q: What warranty comes with it?
A: The module includes a 12-month warranty.
Q: How do I pick the right module for my panel?
A: First, count the current for all I/O slices. Then, keep total draw under 10 A. Also, use one module per segment for fault isolation. Next, check your controller family. Finally, confirm the 24 Vdc supply range.
Q: What is a common field mistake?
A: Many users forget the segment cap. As a result, they add too many slices. The fuse then trips. Therefore, always leave current margin. Also, check polarity before power-up.
Q: When should I choose a different module?
A: Choose another unit if your segment needs more than 10 A. Also, choose another unit if your controller is not in the Modicon TM5 family.

Buying Guide

First, confirm your controller supports Modicon TM5.
Then, add up the current for all planned I/O slices.
Also, keep the total below 10 A.
Moreover, use one TM5SPS2 per segment for clean fault isolation.
In addition, check that your 24 Vdc supply stays in the 20.4–28.8 Vdc range.
Furthermore, order spare fuses and one spare module for critical lines.
Next, verify the IP20 cabinet environment.
Finally, ask for help if your load is close to the limit.
