Product details
TSXPCX1031 – RS232 Connecting Cable for DTE Terminal Port, 2.5m
Brand: Modicon / Schneider Electric
Model: TSXPCX1031
Type: Connection Accessory, RS232 Cable
This cable links DTE terminal ports to Modicon X80, Premium, Micro, Twido, and Magelis panels. It supports Modbus, Uni-Telway, and character mode protocols. The 2.5m length provides flexible placement. It includes a SUB-D 9‑way female to 25‑way male adaptor for wider compatibility.
Technical Data
- Physical Interface: RS232 and RS485
- Connectors: 1x mini DIN 8‑pin female, 1x SUB‑D 9‑pin female
- Protocols: Modbus, Uni‑Telway, Character mode
- Cable Length: 2.5 m (8.2 ft)
- Weight: 0.17 kg (0.37 lb)
- Temperature Range: 0 °C to +60 °C (operating)
- Storage Temperature: -25 °C to +85 °C
- Humidity: 5% to 95% RH (non‑condensing)
- EMC Immunity: EN 61000‑6‑2 industrial environment
- RoHS Compliant: Yes, lead‑free materials
Installation & Setup
- Plug & Play: No driver installation required
- Connection: Attach mini DIN to DTE port, SUB‑D to device
- Adaptor: Use included 9‑to‑25 pin adaptor for legacy ports
- Polarity: Standard RS232 pinout, verify with device manual
- Grounding: Use shielded cable for noisy environments
Compatibility
- Modicon X80 – all CPU and communication modules
- Modicon Premium – TSX P57, TSX P47 series
- TSX Micro – TSX 37, TSX 57 compact PLCs
- Twido – TWDLMDA, TWDLCAA controllers
- Magelis GTO & XBT – HMI terminals with DTE port
Applications & Use Cases
- PLC programming and firmware updates
- HMI to controller data exchange
- Field device configuration (drives, sensors)
- Legacy system integration with Modbus networks
- Remote diagnostics via Uni‑Telway
Certifications & Standards
- CE marked, UL recognized
- RoHS and REACH compliant
- EN 61131‑2 for PLC peripherals
- Industrial EMC: EN 61000‑6‑2 & EN 61000‑6‑4
Package Contents
- 1x RS232 connecting cable (2.5m)
- 1x SUB‑D 9‑way female to 25‑way male adaptor
- Warranty card and quick start guide
Warranty & Shipping
- Warranty: 12 months against manufacturing defects
- Dispatch: 12‑24 hours after order confirmation
- Carriers: FedEx, UPS, DHL (tracking provided)
Manager’s Insight
This cable is the standard for Modicon field upgrades. Its rugged design ensures reliable data transfer in harsh plants. The included 9‑to‑25 adaptor saves engineers from hunting for extra parts. For quick commissioning, keep one in every service kit.
Expert Review
Well‑built and fully shielded. Protocol support covers legacy and modern networks. The 2.5m length balances reach and signal integrity. Ideal for permanent installation or portable programming. A solid choice for Schneider Electric ecosystems.
Frequently Asked Questions
- Can I use this cable with a non‑Modicon device?
Yes, if the device has a DTE RS232 port with standard pinout. - Does it support baud rates above 115200?
Yes, it handles up to 115200 bps; for higher speeds verify device capability. - Is the adaptor required for all connections?
Only for 25‑pin D‑sub ports. For 9‑pin ports, use the cable directly. - What is the minimum bending radius?
Recommend 50 mm to prevent internal wire damage. - Can I extend the cable length?
Use a gender changer and extension cable, but total length should not exceed 15 m. - Is it compatible with Modicon M340?
No, M340 uses a different pinout; use TSXPCX3031 for M340.
Selection Guide
- For X80, Premium, Micro, Twido: choose TSXPCX1031
- For M340 or Quantum: select dedicated cables
- For longer reach: consider 5m or 10m variants
- For USB conversion: use a RS232‑to‑USB adaptor with this cable
- Always check your device DTE/ DCE configuration
