Schneider Electric 52-0402-000 Tap Terminator Overview
- 52-0402-000 is a dedicated tap terminator for Modicon Quantum systems.
- It ensures clean signal ends in RS-485 networks.
- The device improves data stability on unused drops.
- Designed for long-term industrial operation.
Core Advantages
- Signal integrity improvement on Modbus lines.
- Low power use reduces system load.
- Compact size fits tight control panels.
- Fast installation saves engineering time.
- Built for demanding factory conditions.
Electrical and Communication Data
- Manufacturer: Schneider Electric
- Product Line: Modicon Quantum
- Part Number: 52-0402-000
- Accessory Type: Tap terminator
- Signal Protocol: RS-485 / Modbus
- Input Voltage: 24V DC nominal
- Voltage Tolerance: ±10%
- Current Draw: 40 mA typical
- Power Dissipation: Less than 1 W
- Supported Cable Length: Up to 100 m
- Termination Resistance: Optimized for RS-485
Environmental and Mechanical Details
- Operating Temperature: -20°C to +70°C
- Storage Temperature: -40°C to +85°C
- Humidity Range: 5% to 95% non-condensing
- Protection: Built-in surge suppression
- Status Feedback: LED indication
- Mounting Options: DIN rail or panel mount
- Connector Style: Screw or plug-in terminals
- Net Weight: Approx. 5 g
Compliance and Quality
- CE certified for industrial use.
- UL listed for safety assurance.
- RoHS compliant materials.
Typical Use Scenarios
- Unused drop termination in Quantum networks.
- RS-485 Modbus communication lines.
- Large PLC control architectures.
- Factory automation backbones.
Package Contents
- 1 × Schneider Electric 52-0402-000 unit
- Factory-sealed original packaging
Warranty and Logistics
- 12-month warranty against manufacturing defects.
- Worldwide shipping via FedEx, UPS, or DHL.
- Carefully packed for global transport.
FAQ
- Why is a tap terminator needed?
- It prevents signal reflection on unused drops.
- Can it be used on active communication ports?
- No, it is designed for unused locations only.
- Does cable length affect performance?
- Shorter runs improve overall signal quality.
- Is special setup required?
- No configuration is needed after wiring.
- What improves long service life?
- Stable power and clean grounding help most.
