Schneider Electric 140ERT85410 Multifunction Input Module | Modicon Quantum

Product Overview

The Schneider Electric 140ERT85410 multifunction input module delivers reliable signal handling for Modicon Quantum PLC systems.

• Brand: Schneider Electric.
• Model: 140ERT85410 from the Modicon Quantum series.
• Type: Multifunction input module for industrial PLC applications.

Technical Highlights

• Two isolated channel groups support sixteen process inputs each.
• The module processes thirty-two discrete inputs plus one clock signal input.
• Optocoupler isolation improves noise resistance and system stability.
• Power consumption stays below 7.5 W.

Connection and Signaling

• Forty screw-type terminals ensure secure field wiring.
• The design supports shielded and unshielded signal cables.
• Maximum cable length reaches 600 m.
• Thirty-five LEDs provide clear local status indication.

Environmental Limits

• Operating temperature range supports 0°C to 60°C.
• Storage temperature range extends from -40°C to 85°C.
• The module tolerates up to 95% RH without condensation.
• Stable operation continues up to 5,000 m altitude.

Installation Notes

• Mount the module in a compatible Modicon Quantum PLC rack.
• Tighten terminals evenly to maintain signal integrity.
• Separate signal and power wiring to reduce interference.

Package and Delivery

• Package includes one Schneider Electric 140ERT85410 module.
• Protective packaging supports safe global transport.
• Shipping services include FedEx, UPS, and DHL.
