Schneider BMXXBC015K X-bus Expansion Cable 1.5m for M340 M580

Product Overview

• Model BMXXBC015K is a Modicon X80 X-bus expansion cable.
• It connects multiple racks in a daisy-chain setup.
• This cable supports shared I/O for M340 and M580 platforms.
• Lifecycle status: Active as of September 2026.
• Length: 1.5 m. Connector: 9-pin SUB-D.
• Maximum X-bus total length: 30 m.

Technical Specifications

• Brand: Schneider Electric
• Model: BMXXBC015K
• Series: Modicon X80
• Type: X-bus expansion cable
• Length: 1.5 m
• Connector: 9-pin SUB-D
• Function: Daisy-chain X-bus connection between racks
• Max X-bus total length: 30 m
• Measurement range: Not applicable for this cable
• Frequency response: Not applicable for this cable
• Sensitivity: Not applicable for this cable
• Linearity: Not applicable for this cable
• Resolution: Not applicable for this cable
• Temperature range: Follows Modicon X80 platform specs
• Environmental tolerance: Matches X80 system requirements
• Noise immunity: Designed for industrial X-bus signals

Compatibility and Use Cases

• Works with Modicon M340 and Modicon M580 racks.
• Ideal for multi-rack I/O expansion in control cabinets.
• Suits factory automation, process control, and machine building.
• Used where short-distance, reliable X-bus links are needed.
• Not for Ethernet, Profibus, or remote I/O networks.

Installation Guide

• Power down the rack before connecting the cable.
• Plug the 9-pin SUB-D into the X-bus port.
• Secure the connector screws by hand.
• Keep total X-bus length under 30 m.
• Route cables away from high-voltage power lines.
• Check daisy-chain order before power-up.

Commissioning and Maintenance

• Verify LED status on each rack after power-up.
• Check for loose connectors during routine service.
• Replace damaged cable immediately to avoid bus faults.
• No special tools are required for installation.
• Keep spare cables on site for quick swap-outs.

Certifications and Warranty

• Complies with Schneider Electric Modicon X80 standards.
• Meets industrial EMC and safety requirements.
• Warranty: 12 months from delivery date.
• Shipment within 12–24 hours after order.
• Delivery by FedEx, UPS, or DHL.

Packing List

• 1 × BMXXBC015K X-bus expansion cable
• 1 × Protective antistatic bag
• 1 × Document with part number and batch info

Manager’s Insight

• This cable is a simple but critical link for X80 racks.
• It saves wiring time in multi-rack architectures.
• Short length reduces cable clutter in crowded cabinets.
• Active lifecycle means long-term availability.
• Best for engineers who need reliable, low-cost expansion.

Expert Review

• The BMXXBC015K does one job well: connect X-bus racks.
• Build quality matches Schneider Electric industrial norms.
• The 9-pin SUB-D connector locks firmly in place.
• Installation is fast and does not need extra adapters.
• Users should respect the 30 m total bus limit.
• It is not a data cable for high-speed networks.

FAQ

• Q: What is the BMXXBC015K used for?
  A: It links X-bus ports between Modicon X80 racks.
• Q: How long is this cable?
  A: The cable measures 1.5 meters.
• Q: Which PLCs support this cable?
  A: It works with Modicon M340 and M580 systems.
• Q: Can I use it outdoors?
  A: It is designed for control cabinet use, not outdoor exposure.
• Q: What is the maximum bus length?
  A: The total X-bus length must not exceed 30 meters.
• Q: How fast do you ship?
  A: Orders ship in 12–24 hours via FedEx, UPS, or DHL.
• Q: Is there a warranty?
  A: Yes, it includes a 12-month warranty.
• Q: Can I install it myself?
  A: Yes, if you follow the installation guide above.
• Q: What if the connector feels loose?
  A: Tighten the screws gently and check the port.
• Q: Do you offer bulk pricing?
  A: Contact our sales team for volume orders.

Buying Guide

• Confirm your rack uses an X-bus expansion port.
• Measure the distance between racks before ordering.
• Choose this 1.5 m cable for short cabinet runs.
• Order a longer X-bus cable if you need more reach.
• Keep total bus length below 30 m.
• Buy from an authorized source for warranty support.
• For urgent projects, ask about expedited shipping.
• Email sales@powergearx.com for stock checks.
• Or message +86 18030005825 on WhatsApp.

Order and Support

• Inquiries: sales@powergearx.com
• WhatsApp: +86 18030005825
• Ships in 12–24 hours by FedEx, UPS, or DHL.
• Warranty: 12 months from delivery.
