Schneider 170XTS00701 Busbar Connector | Modicon Momentum

Schneider Electric 170XTS00701 Busbar Connector

The 170XTS00701 links Modicon Momentum I/O bases quickly and securely.

Core Benefits

• One-row layout saves panel space for dense racks.
• Spring-type terminals give fast, tool-free connections.
• High-conductivity metal cuts voltage drop and heat.
• Vibration resistance keeps contact tight in moving sites.
• Plug-in mount speeds field swaps and reduces downtime.

Technical Details

• Manufacturer: Schneider Electric
• Model: 170XTS00701; Series: Modicon Momentum
• Type: 1-row busbar connector for discrete and analog bases
• Terminal: spring-clamp type for fast wiring
• Rated current: up to 12 A per contact under normal load
• Contact resistance: < 5 mΩ typical
• Insulation resistance: > 100 MΩ at 500 V DC
• Dielectric strength: withstands 1500 V for 1 second in test
• Operating temp: -25 °C to +70 °C
• Storage temp: -40 °C to +85 °C
• Material: high-conductivity copper alloy with corrosion finish
• Mount: plug-in to Modicon Momentum rack slot
• Weight: approx 0.11 kg (0.25 lbs)

Performance & Reliability

• Low-resistance paths cut heat under sustained load.
• Spring terminals maintain pressure during thermal cycles.
• Thick metal traces resist wear from repeated insertions.
• High insulation reduces cross-talk in mixed I/O racks.
• Corrosion finish extends life in humid enclosures.

Install Tips

• Align connector pins before full insertion to avoid bending.
• Use recommended torque on neighboring terminal blocks only.
• Route busbar wiring away from drive and power cables.
• Check contact pressure after field vibration or transport.
• Keep the connector and rack slot clean during install.

Package & Shipping

• One 170XTS00701 busbar connector packed with protective foam.
• Quick install note included for fast setup.
• Shipping options: FedEx, UPS, or DHL with tracking.
• 12-month warranty starts from delivery date.

Contact

• Email: sales@powergearx.com
• WhatsApp: +86 18030005825

Technical FAQ

• Q: How do I test contact resistance safely?
  A: Use a low-resistance meter on a de-energized connector. Record values and compare to baseline.
• Q: Can I use this connector in a dusty cabinet?
  A: Yes, but add a filtered vent and clean contacts yearly to keep performance.
• Q: What checks reduce intermittent faults after shipping?
  A: Re-seat the connector and inspect spring clamps for debris or deformation.
• Q: How to reduce heat in tightly packed racks?
  A: Add small forced-air fans and leave clearance above the busbar row.
• Q: What maintenance keeps this connector reliable for years?
  A: Schedule visual inspections and measure contact resistance every 12 months.
