Product details
Product Description
- 170MCI02110 is a round shielded cable from Schneider Electric’s Modicon Momentum series.
- It links Momentum I/O bases using a 20-pin male to 20-pin female connection.
- The cable is 2 meters long, giving enough reach for most cabinets.
- Rated for 30 V and 1 A, it fits many control signals.
- Foil and drain shielding reduce electromagnetic interference.
- Works in temperatures from -10°C to +60°C.
- Made with copper conductors and a tough PVC jacket.
- RoHS compliant for environmental safety.
Technical Specifications
- Brand: Schneider Electric
- Model: 170MCI02110
- Series: Modicon Momentum
- Type: Communication Cable
- Connector A: 20-pin male
- Connector B: 20-pin female
- Length: 2 meters (typical)
- Voltage: 30 V
- Current: 1 A
- Wire Gauge: 26 AWG
- Conductor: Copper
- Shielding: Foil + drain wire
- Jacket: PVC
- Interface: Proprietary MODBUS / Momentum I/O
- Temperature Range: -10°C to +60°C
- RoHS: Yes
Application & Compatible Devices
- Connects Momentum I/O bases in distributed control systems.
- Works with Momentum processors and analog/digital I/O modules.
- Ideal for PLC panels, material handling, and packaging lines.
- Suitable for factory automation and building management.
Installation & Maintenance
- Simply plug the 20-pin connectors into matching ports.
- Route the cable away from high-power lines to avoid noise.
- Check the locking clips for a secure fit.
- No special tools needed for routine inspection.
- Clean with a dry cloth; keep connectors free of dust.
Shipping & Warranty
- 12-month warranty against defects.
- Dispatch within 12–24 hours after order.
- Shipping via FedEx, UPS, or DHL with tracking.
Comparison with Similar Models
- 170MCI02120 – longer 3m cable for wider spans.
- 170MCI02100 – unshielded version for low-noise areas.
- 170MCI02130 – high-flex cable for moving applications.
Expert Review
- “The 170MCI02110 is a solid choice for Momentum base connections. Its shielding effectively suppresses noise in industrial environments. The 2m length is practical for most cabinets, and the PVC jacket handles regular wear. A reliable cable for critical I/O links.”
- – Senior Controls Engineer
Manager’s Insight
- “We recommend this cable for its proven performance and quick delivery. The 12-month warranty and 24h shipping give our customers confidence. It simplifies spare parts management and reduces downtime during maintenance.”
- – Product Manager, Powergear X
Frequently Asked Questions (FAQ)
- Q: Can this cable connect two Momentum processors directly?
- A: No, it connects I/O bases to each other or to a processor base.
- Q: Is the 170MCI02110 compatible with third-party PLCs?
- A: It uses a proprietary Momentum interface, so it only works with Modicon Momentum equipment.
- Q: How do I know if the shielding is effective?
- A: The foil and drain wire reduce noise; for best results, ground the drain at one end.
- Q: What is the minimum bend radius for this cable?
- A: Approximately 5x the cable diameter – avoid sharp bends to protect conductors.
- Q: Can I use this cable in outdoor applications?
- A: No, it is rated for indoor use only (temperature -10°C to +60°C).
- Q: What should I do if the cable fails within the warranty period?
- A: Contact our support for a replacement under the 12-month warranty.
- Q: Is there a longer version available?
- A: Yes, see the 170MCI02120 (3m) or 170MCI02130 (5m) for longer distances.
Selection Guide
- Choose 170MCI02110 for standard 2m connections between Momentum bases.
- Select shielded cables for environments with high electrical noise.
- For moving parts, pick the high-flex variant (170MCI02130).
- Always verify connector orientation before plugging.
