Product details
Overview
The Bently Nevada 330101-00-27-50-02-CN is a top – notch 3300 XL 8 mm probe produced in the U.S.A. It comes with a 3/8 – 24 UNF thread and no armor. Thanks to its patented TipLoc molding and CableLoc design, it outperforms previous models. The optional FluidLoc cable can prevent liquid leakage.
Technical Specification
- Brand: Bently Nevada
- Model: 330101-00-27-50-02-CN
- Suffix Meaning:
- “00” indicates an unthreaded length of 0.0 inches.
- “27” represents an overall case length of 2.7 inches.
- “50” stands for a total length of 5.0 meters.
- “02” denotes a miniature coaxial ClickLoc connector with a standard cable.
- “CN” is for country – specific approval.
- Suffix Meaning:
- Weight: It weighs 323 g/m (11.4 oz).
- Temperature Range: The standard probe operates from – 52°C to +177°C, while the extended – temperature – range probe has different limits for the tip, cable, and connector.
- Pressure: The probe is designed to seal differential pressure with a Viton® O – ring, though it’s not pressure – tested before shipment.
- Relative Humidity: There is less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity for up to 56 days.
For any inquiries, please contact: sales@powergearx.com
For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
