Product details
Product Overview
Mitsubishi Electric designed the MR-J3-100A servo amplifier for precise and stable industrial motion control applications.
Core Value
- The MR-J3-100A delivers 1000W output power for demanding automation systems.
- MELSERVO J3 architecture ensures smooth torque control and high-speed response.
- Built-in dynamic brake and regenerative resistor improve stopping accuracy and energy recovery.
Technical Specifications
- Brand: Mitsubishi Electric | Model: MR-J3-100A | Category: AC Servo Drive
- Main circuit: 200–230VAC, 3-phase, 5A rated current
- Output: 170VAC, 3-phase, 6A rated current
- Control circuit: 200–230VAC, 1-phase, 0.2A, 30W consumption
- Sine-wave PWM control for precise speed, torque, and position
- Operating temperature: 0 to +55°C, force-cooled open enclosure
Control & Reliability
- Advanced current control ensures fast response and stable servo loops
- High-resolution absolute encoder improves positioning accuracy
- Noise immunity protects against industrial electromagnetic interference
Installation Guidelines
- Install vertically inside a ventilated cabinet
- Maintain clearance around unit for optimal cooling
- Discharge capacitors for 5 minutes before maintenance
Packaging Contents
- One Mitsubishi Electric MR-J3-100A servo amplifier
- Built-in regenerative resistor and dynamic brake included
- Packaged for FedEx, UPS, DHL shipping
FAQ
- What applications benefit most?
- CNC machines, robotics, conveyors, and precision assembly
- How does the dynamic brake improve safety?
- Dissipates kinetic energy to reduce overshoot and protect machines
- Can it operate continuously?
- Yes, with proper cooling and wiring for industrial duty cycles
