LMS511-21100 Laser Scanner – 80m Range, 190° Outdoor | SICK

Product Overview

• LMS511-21100 – a bar code scanner controller from SICK.
• Part of the LMS500 series for outdoor/indoor use.
• High-resolution scanning with 190° horizontal aperture.
• Infrared laser (905 nm) – Class 1 for eye safety.

Key Features

• Scanning range – up to 80 m working range.
• High resolution – 0.25°, 0.5°, or 1° angular resolution.
• Flexible scanning frequency – 25, 35, 50, or 75 Hz.
• Fast response – ≥13 ms.
• Weatherproof – IP65/IP67, -30°C to +50°C.
• Integrated heating – for cold environments.
• Multiple interfaces – Ethernet, RS-232/422, USB.
• High accuracy – ±12 mm measurement accuracy.

Technical Specifications

• Brand – SICK
• Model – LMS511-21100
• Series – LMS500
• Type – Laser scanner / bar code scanner controller
• Application – Outdoor and indoor
• Variant – Lite
• Resolution – High Resolution
• Light source – Infrared (905 nm, ±10 nm)
• Laser class – 1 (safe for eyes)
• Aperture angle – 190° (horizontal)
• Scanning frequency – 25, 35, 50, 75 Hz (selectable)
• Angular resolution – 0.25°, 0.5°, or 1°
• Working range – 0.2 m to 80 m
• Range at 10% remission – 26 m
• Measurement accuracy – ±12 mm
• Systematic error – ±25 mm (1-10m), ±35 mm (10-20m)
• Statistical error – 7 mm (1-10m), 9 mm (10-20m)
• Response time – ≥13 ms
• Supply voltage – 24 V DC, ±20%
• Power consumption – 22 W (55 W with heating)
• Housing material – AlSi12
• Housing color – Gray (RAL 7032)
• Window material – Polycarbonate, scratch-resistant
• Enclosure rating – IP65 / IP67
• Protection class – III
• Weight – 3.7 kg
• Dimensions (L×W×H) – 160×155×185 mm
• MTBF – >100 years

Interfaces & Connectivity

• Ethernet – TCP/IP, UDP/IP, OPC DA, NTP.
• Serial – RS-232 / RS-422 (9.6 kBaud to 500 kBaud).
• USB – Mini-USB for service interface.
• Digital I/O – 2 inputs, 3 outputs.
• Connection type – 4× M12 round connectors.
• Optical indicators – 5 LEDs + 7-segment display.

Filters & Features

• Echo filters – Fog, particle, glare, average filters.
• Field evaluation – 4 field sets, 4 simultaneous cases.
• Object shape – detects almost any shape.
• Heating – integrated self-heating for cold operation.

Environmental & Certifications

• Operating temp – -30 to 50°C.
• Storage temp – -40 to 70°C.
• Ambient light immunity – 70,000 lx.
• Object remission – 2% to >1000%.
• EMC – Industrial environment per IEC 61000-6-2/-6-3.
• Vibration – 10 Hz to 150 Hz, 0.35 mm to 5 g.
• Shock – 15 g, 11 ms (6 shocks/axis).
• Impact resistance – IK05, IK06, IK07.

Installation & Maintenance

• Mounting – use mounting bracket (not included).
• Alignment – adjust for 190° horizontal field.
• Wiring – use M12 connectors; follow pinout.
• Cleaning – clean polycarbonate window with soft cloth.
• Diagnostics – LEDs and 7-segment display show status.

Packaging & Delivery

• Includes – 1 LMS511-21100 scanner, quick guide.
• Warranty – 12 months against defects.
• Shipping – 12‑24 hours via FedEx, UPS, or DHL.

Expert Review

• Manager’s Insight: “The LMS511-21100 is a rugged workhorse for outdoor scanning. With 80 m range, 190° aperture, and IP67 rating, it handles harsh conditions with ease. The selectable scanning frequency and resolution make it adaptable to any application.”

Applications

• Best for – Port automation, outdoor profiling, volume measurement, and collision avoidance.
• Works with – PLCs, industrial PCs, and automation networks.
• Used in – Ports, mines, quarries, and heavy industry.

Comparison

• LMS511-21100 vs. LMS511-21101 – 21100 has 190° aperture; 21101 has 270°. Choose based on coverage need.
• LMS511-21100 vs. LMS111-21100 – LMS111 is 50 m range; LMS511 is 80 m. Pick LMS511 for longer distances.
• LMS511-21100 vs. LMS500-21100 – LMS500 is standard variant; LMS511 has higher resolution. Choose LMS511 for fine detail.
• Compare details: SICK LMS500 Series

FAQ

• Q: What is the maximum scanning range?
  A: 80 meters.
• Q: Can I use this scanner outdoors?
  A: Yes, it is rated for outdoor use with IP65/IP67.
• Q: What laser class is it?
  A: Class 1 – safe for eyes.
• Q: What scanning frequencies are available?
  A: 25, 35, 50, or 75 Hz.
• Q: What interfaces does it have?
  A: Ethernet, RS-232/422, USB, and digital I/O.
• Q: What is the response time?
  A: ≥13 ms.
• Q: Does it have heating for cold weather?
  A: Yes, integrated self-heating.
• Q: What is the warranty period?
  A: 12 months from purchase.
• Q: How fast is delivery?
  A: We ship within 12‑24 hours via FedEx, UPS, or DHL.

Selection Guide

• Choose LMS511-21100 if:
  • You need outdoor scanning up to 80 meters.
  • Your application requires 190° horizontal coverage.
  • You want high resolution with selectable frequency.
• Consider other models if:
  • You need 270° coverage – choose LMS511-21101.
  • You need shorter range (50 m) – check LMS111 series.
  • You need lower resolution – choose LMS500 standard.
• Pro tip: For outdoor use, enable the heating function in cold weather for reliable operation.
