Honeywell 900P01-0501 120/240VAC Power Supply
The Honeywell 900P01-0501 is a rugged AC/DC power supply for industrial automation. It accepts wide-range input from 90 to 264 VAC. Delivers stable 58W output with built-in protection. Features screw terminals for easy wiring and test jacks for quick diagnostics. Reliable power for your Honeywell control systems.
Model Breakdown
- 900P01 (Power Supply Series)
- 0501 (Specific Model)
- 05 – 58W output rating
- 01 – 120/240VAC input version
- 0501 (Specific Model)
Technical Specifications
- Brand: Honeywell
- Model: 900P01-0501
- Type: 120/240VAC Power Supply
- Input Voltage: 90 to 264 VAC, 47-63 Hz
- Input Current: 1.4 A max continuous
- Inrush Current: 40A peak for 120ms at 240V
- Input Rating: 130 VA
- Output Rating: 58W
- Fuse: Internal, non-replaceable
- Hold-up Time: 20ms at 115VAC, full load
- Wiring: Screw terminals, 12-22 AWG
- Test Jacks: 5 VDC and 24 VDC
- Temperature: T4 rated, 0°C to 60°C
What’s Included
- 1x 900P01-0501 Power Supply unit
- 1x Installation manual
- 1x Warranty card
- Screw terminals pre-installed
Installation Guide
- Mount: Secure on DIN rail or panel
- Wire: Use screw terminals (12-22 AWG)
- Connect AC: 90-264VAC, 47-63Hz supply
- Test: Use 5V and 24V test jacks
- Ground: Follow local electrical codes
Key Features
- Wide input: 90-264VAC works anywhere
- Compact: Saves panel space
- Test points: Quick voltage checks
- Hold-up: 20ms ride-through for stability
- T4 rated: Reliable in industrial heat
- Safe: Internal fuse protection
Typical Applications
- Power Honeywell controllers and I/O
- Industrial automation panels
- Process control systems
- Factory floor equipment
- Building management systems
Environmental Ratings
- Operating Temp: 0°C to +60°C
- Storage Temp: -40°C to +85°C
- Humidity: 5% to 95% non-condensing
- Certifications: CE, UL, T4 rated
Warranty & Support
- 12-month warranty against defects
- Technical support available
- Repair or replacement coverage
Shipping Information
- Couriers: FedEx, UPS, DHL
- Tracking: Provided upon dispatch
- Global: Fast worldwide delivery
Professional FAQ
- Q: Can I use this power supply with 240VAC input?
- A: Yes. The 900P01-0501 accepts 90-264VAC, so 240VAC works perfectly.
- Q: What does the internal non-replaceable fuse mean?
- A: The fuse is soldered inside for safety. If it blows, the unit needs replacement. This prevents improper field repairs.
- Q: What are the test jacks for?
- A: Use the 5V and 24V test points to verify output voltages quickly with a multimeter during troubleshooting.
- Purchase Guide: I need a power supply for a Honeywell C300 system. Is this the right model?
- A: Yes. The 900P01-0501 is commonly used with Honeywell Series C systems. Check your total load; 58W supports most I/O configurations.
- Experience-based Q&A: Our plant has frequent voltage sags. Will this power supply ride through?
- A: Yes, it offers 20ms hold-up time at full load. For longer sags, consider an external UPS. The wide input range also helps with fluctuations.
