HIMA F 3331 8 Channel Safety-Related Output Module

Technical Specifications:

• Brand: HIMA
• Model: F 3331 8 Channel Safety-Related Output Module
• Outputs: 8 Channels, 500 mA max, short-circuit proof
• Voltage Drop: Max. 2 V at 500 mA
• Line Resistance: Max. 11 Ohm (in + out)
• Undervoltage Tripping: ≤ 16 V
• Operating Current:
  • 5 V DC: 130 mA
  • 24 V DC: 180 mA (with additional load)
• Test Signal Duration: Max. 200 µs
• Space Requirement: 4 TE
• Operating Points:
  • Short-Circuit Current: 0.75 … 1.5 A
  • Line Break: 0.5 … 9.5 mA
  • Output Leakage Current: Max. 350 µA
  • Output Voltage (if reset): Max. 1.5 V

Frequently Asked Questions (FAQ):

Q: What are the main safety features of the F 3331 module?
A: The F3331 integrates safety shutdown, safe isolation, and line monitoring, ensuring fault detection during normal operation, along with automatic testing and signal feedback.

Q: What types of loads can the F3331 handle?
A: The module can handle both resistive and inductive loads up to 500 mA, as well as lamps up to 4 W.

Q: Can the HIMA F3331 be used in industrial applications?
A: Yes, the module is designed for high-reliability applications in process automation, industrial control, and machine safety systems.

Q: How does the line monitoring function work?
A: Line monitoring continuously checks the output lines for faults or interruptions, triggering alerts if issues are detected.

For more detailed information, please check official datasheet: F 3331 8 fold output module testable
