GT2712-STWD Mitsubishi GOT2000 HMI | 12.1-Inch SVGA Touch Panel Terminal

GT2712-STWD – Mitsubishi GOT2000 Graphic Operation Terminal (HMI)

This HMI offers clear visual control for machines. It has a 12.1-inch SVGA TFT screen with 65,536 colors. The analog touch panel works with gloves. Built for factories, it lasts long and connects easily.

Key Features

• • 12.1-inch TFT display – SVGA (800 x 600 pixels), sharp details.
  • 65,536 colors – bright, clear graphics.

• Analog resistive touch – works with gloves; 1 million touches life.
• LED backlight – 60,000 hours life at 25°C.
• SD card slot – up to 32 GB (SDHC) for data logs.
• Multiple ports – Ethernet, RS-232, RS-422/485, 2 USB host, 1 USB device.
• Durable – noise immunity 500 Vp-p, wide temp range 0°C to 50°C.

Technical Specifications

• Manufacturer & Model
  • Brand: Mitsubishi Electric
  • Series: GOT2000 Series
  • Part Number: GT2712-STWD
  • Type: Graphic Operation Programmable Terminal (HMI)
• Display System
  • Screen Size: 12.1 inches (W: 246 mm x H: 184.5 mm)
    • Resolution: SVGA (800 x 600 pixels)
    • Technology: TFT color LCD
    • Colors: 65,536
  • Backlight: LED
    • Lifespan: 60,000 hours at 25°C, 50% brightness
• Touch Panel
  • Type: Analog resistive film
  • Durability: 1 million touches minimum
• Interfaces & Connectivity
  • Ethernet: 1 channel, 100BASE-TX
  • Serial: RS-232, RS-422/485
  • USB Ports
    • USB Host: 2 channels
    • USB Device: 1 channel
  • SD Card Slot: 1 slot, supports SDHC up to 32 GB
• Power & Electrical
  • Supply Voltage: 24 V DC (+25%, -20%)
  • Max Power Consumption: 45 W
  • Noise Immunity: 500 Vp-p
  • Withstand Voltage: 350 V AC for 1 minute
• Environmental Ratings
  • Operating Temperature: 0°C to 50°C
  • Storage Temperature: -20°C to 60°C
  • Protection: Front panel IP67F (when mounted)
• Physical
  • Weight: 9.07 kg (20.00 lbs)
  • Dimensions: 12.1-inch standard cutout

Easy Setup & Care

• Panel mount with brackets – quick to install.
• Front USB port helps upload projects without opening cabinet.
• SD card slot adds extra storage for recipes or logs.
• LED backlight – no lamp changes needed.
• Self-diagnostic tools reduce downtime.

Expert Review – Why It Stands Out

Automation engineers value the GT2712-STWD for its reliable touch response and wide connectivity. The SD card slot offers easy data backup. Ethernet and dual serial ports support legacy and modern PLCs. This HMI handles harsh factory noise well.

Manager’s Insight – Smart Choice for Operations

Plant managers like the long LED life – less maintenance cost. The 12.1-inch screen is large enough for complex dashboards. Quick setup and SD logging improve productivity. It’s a cost-effective HMI for mid-size lines.

Where to Use & Compatible Equipment

• Assembly Lines – show real-time output and alarms.
• Packaging Machines – control speed, temperature, and counters.
• HVAC Systems – monitor air handling and energy data.
• CNC Machines – display tool status and program selection.
• Food & Beverage – wash-down areas with IP67F front.
• Works with Mitsubishi PLCs (iQ-R, iQ-F, Q, L, FX) and third-party devices via Modbus.

Frequently Asked Questions

• What is the difference between GT2712-STWD and smaller GOT2000 models?
• This model gives a 12.1-inch SVGA screen, SD card slot, and higher noise immunity. Ideal when you need extra storage and robust communication.
• Can I store production data on the SD card?
• Yes. The SDHC slot supports up to 32 GB. You can log alarms, recipes, and trends directly to the card.
• Does this HMI support remote access over Ethernet?
• Absolutely. The built-in 100BASE-TX port enables web server functions and remote monitoring with GT Works3 or SCADA.
• What is the warranty and shipping policy?
• We provide 12-month warranty covering defects. Orders ship within 12-24 hours via FedEx, UPS, or DHL.
• Which communication cables work best with this HMI?
• Use standard RS-232 or Ethernet cables. For vibration monitoring systems, consider Bently Nevada cables like 330190-070-00-05 or 330190-070-00-CN when pairing with proximity probes.

Purchasing & Selection Guide

• Pick GT2712-STWD if you need a mid-size HMI with SD card logging and glove-friendly touch.
• Check your PLC communication: Ethernet, RS-232, or RS-422/485 are all supported.
• Ensure your panel cutout matches standard 12.1-inch dimensions.
• For harsh electrical noise environments, this unit offers 500 Vp-p immunity.
• Compare with similar models – we also offer compatible cables for monitoring systems.
