Name: GT27-MMR-Z Mitsubishi GOT2000 Multimedia Unit – Video Recorder
SKU: GT27-MMR-Z
Availability: InStock

Product details

Add video input, recording, and playback to your GT27 HMI. Compact, plug-and-play, and built for factory media tasks.

▶ General Info
- ▪ Brand: Mitsubishi Electric
- ▪ Model: GT27-MMR-Z
- ▪ Series: GOT2000 Series
- ▪ Type: Multimedia unit (video input & recording module)
- ▪ Compatibility: GT27 model only
▶ Video & Audio Specs
- ▪ Input signal: Composite video (NTSC / PAL)
- ▪ Video channels: 1 channel
- ▪ Connector: BNC (twist-lock, stable)
- ▪ Audio input: Stereo via 3.5mm mini-jack
▶ Recording & Playback
- ▪ Storage media: CompactFlash (CF) card
- ▪ Function: Records video to CF card, plays back files directly on GT27 screen
- ▪ No extra PC needed – standalone operation
▶ Physical & Installation
- ▪ Weight: approx. 0.41 kg (0.9 lbs) – lightweight
- ▪ Mounting: Plugs into GT27 rear slot, no extra cabinet space

💡 Expert Review – “Simple, Reliable Video for HMIs”
“The GT27-MMR-Z turns your GT27 into a video-enabled terminal. Setup is easy: plug the BNC cable, insert a CF card, and record. No complex configuration. For machine builders, this means quick troubleshooting with on-screen video playback. The stereo audio input adds clarity for alarm verification.” — Senior Field Engineer
📊 Manager’s Insight – “Cost-Effective Media Integration”
Adding video recording without extra standalone DVRs saves panel space and wiring. The CF card approach is rugged and easy to replace. With 12-month warranty and fast shipping, this module reduces downtime when you need live visuals on your HMI.

✅ Compatible devices: Mitsubishi GT27 series HMIs (GOT2000 platform).
✅ Perfect for these applications:
- ▪ Machine vision monitoring: see camera feeds on HMI screen.
- ▪ Process troubleshooting: record machine cycles to review faults.
- ▪ Quality control stations: capture video evidence of production steps.
- ▪ Security & access logging: record operator actions or area surveillance.
- ▪ Training & documentation: save operation sequences for replay.

Q: What CF card type works best with GT27-MMR-Z?
A: Use industrial-grade CompactFlash cards (512MB to 8GB) formatted in FAT16/FAT32. Avoid high-speed consumer cards – industrial cards ensure stable recording.
Q: Can I record video and watch live feed at the same time?
A: Yes, the unit supports live video display on the GT27 screen while simultaneously recording to CF card. Perfect for real-time observation and backup.
Q: Does this module require additional software or programming?
A: Simple setup via GT Designer3. Just enable the multimedia function, no complex coding. Configuration steps are in the manual.
Q: Is the recorded video playable on a standard PC?
A: Files are stored in proprietary format but can be converted or viewed using Mitsubishi utilities. Contact support for conversion tips.
Q: What is the maximum recording length?
A: Depends on CF card capacity and video quality setting. For a 4GB card, approx. 4–6 hours continuous recording. Loop recording can be set to overwrite oldest files.

📦 What’s included: GT27-MMR-Z unit, installation screws, quick start guide.
🛡️ Warranty: 12 months against defects. Free technical help via email or WhatsApp.
🚚 Fast shipping: Orders ship in 12–24 hours after payment. Carriers: FedEx, UPS, DHL with tracking.
💡 Expert tip: Keep a spare CF card on site. Pre-format cards before first use to avoid recording errors. Use BNC-to-RCA adapter if you have standard CCTV cameras.
✅ Why choose this module: Direct integration with GT27 HMI, no external DVR needed, saves cabinet space and reduces wiring complexity.

Specifications

Dimensions	272 × 214 × 56 mm
Country Of Origin	United States
