GE IS200LSGIH1A Static Starter Control Interface – Reliable EX2100e System Module

GE IS200LSGIH1A Static Starter Control Gating Interface | EX2100e Series

Manufacturer: General Electric (GE)
Model Number: IS200LSGIH1A
Series: EX2100e
Function: Static Starter Control Gating Interface
Condition: New & Original, Factory Sealed
Warranty: 12 Months
Shipping: FedEx, UPS, DHL Available
Author: Powergear X Automation

Contact:
sales@powergearx.com |
+86 18030005825

🔹 Product Overview

The GE IS200LSGIH1A Gating Interface Card is part of the EX2100e excitation system.
It connects the UCSB controller with power conversion bridges and analog outputs.
This module offers fast overcurrent protection and power distribution to essential control components.

• Receives and supplies 28 V DC input voltage
• Transfers ±24 VDC from main supply to control boards
• Distributes power across the control cabinet
• Supports communication with 3 FGPA boards
• Offers built-in overcurrent protection (52SS relay)

 Key Technical Specifications

• Part Number: IS200LSGIH1A
• Voltage: 28 V DC
• Power Distribution: ±24 V DC
• Connection Type: 12-pin plug via copper wire
• Board Type: Printed Circuit Board (PCB)
• System: EX2100e Excitation Control
• Control Collaboration: 3 FGPA boards for thyristor control
• Protection: Opens 52SS relay during fault
• Operating Region: Seismic Code Section 2312 Zone 4
• Weight: 1.8 lbs
• Dimensions: 130 × 85 × 45 mm
• Country of Origin: USA

 Product Highlights

• Protects generator and converter circuits from overcurrent damage
• Maintains stable operation with fast relay response
• Compatible with UCSB, LSTB, FCSA, and 8-Port switch
• Microprocessor and software-based drive control
• High-quality U.S. engineering and build standards

 System Integration

The IS200LSGIH1A interfaces directly with the EX2100e excitation regulator, distributing power and data across subsystems.
It supports bidirectional data exchange with FPGAs for SCR voltage monitoring, improving protection response and system accuracy.

• Interfaces with UCSB controller and bridges
• Works in adjustable frequency drive systems
• Enables communication via copper cabling
• Supports redundant power control and transfer

 Extended System Benefits

• Redundant control architecture (M1, M2, and C)
• Bidirectional, seamless power transfer
• Advanced protection with fault monitoring
• Easy installation and compact design
• Long service life and low maintenance

Recommended Manual

Refer to GEH-6373 Load Commutated Inverter User’s Manual for complete setup and safety procedures.

FAQs

• Q1: What is the main function of GE IS200LSGIH1A?
  A: It acts as a gating interface between the UCSB controller and power bridges, ensuring stable control and overcurrent protection.
• Q2: How does it protect the system?
  A: During an overcurrent, it triggers the 52SS relay to disconnect bridge input power instantly.
• Q3: What voltage does the board operate on?
  A: It runs on 28 V DC input and transfers ±24 V DC for other boards.
• Q4: Can it be used with other EX2100e components?
  A: Yes, it works seamlessly with UCSB, LSTB, and FCSA modules in the EX2100e excitation system.
• Q5: How is the IS200LSGIH1A shipped?
  A: We ship worldwide via FedEx, UPS, and DHL with full insurance and tracking.
