FX2N-32MR-001 Mitsubishi Programmable Controller AC 100-240V Relay Output

Compact programmable controller with 16 DC24V inputs and 16 relay outputs. AC 100-240V power. Reliable solution for general automation tasks.

⚙️ Technical Specifications

• ▪ Brand & Model
  – Manufacturer: Mitsubishi Electric
  – Product No.: FX2N-32MR-001
  – Series: FX2N Series Programmable Controllers
• ▪ I/O Configuration
  – Total I/O points: 32
  – Digital inputs: 16 points, DC24V
  – Digital outputs: 16 relay outputs (2A per point)
• ▪ Power Supply
  – Voltage: AC 100–240 V, 50/60 Hz
  – Power consumption: 40 VA
• ▪ Expandability
  – Supports FX2N expansion modules (analog, temperature, positioning)
  – Max I/O with expansion: up to 256 points
• ▪ Physical & Environment
  – Operating temp: 0°C to +55°C
  – Protection class: IP10
  – Compact footprint for panel installation

📝 Expert Review

The FX2N-32MR-001 offers proven reliability for small to mid-sized machines. Relay outputs handle mixed AC/DC loads easily. Easy to program with GX Developer. A cost-effective choice with long life cycle and wide spare parts availability.

💡 Manager’s Insight

For plant managers, this unit reduces downtime. Simple wiring and modular expansion make upgrades fast. Standardized across many industries, it simplifies spare parts stocking. The relay outputs are robust for frequent switching.

🏭 Applications & Compatible Devices

• ▪ Conveyor systems – controls motors, sensors, and diverters
• ▪ Packaging equipment – reliable relay switching for actuators
• ▪ HVAC control panels – handles fans, dampers, and alarms
• ▪ Small assembly lines – integrates with HMIs and push buttons
• ▪ Works with sensors, relays, contactors, indicator lights, and touch panels
• ▪ Expansion: FX2N-16EX, FX2N-16EYR, analog modules, and more

❓ Frequently Asked Questions

• Q1: Does this PLC have a built-in real-time clock?
  No. The FX2N-32MR-001 does not include an RTC. You can add an FX2N-32BL battery and an FX2N-8AV-BD or use a clock adapter for time-based functions.
• Q2: What programming software is needed?
  Use GX Developer (version 8.0 or later) or GX Works2. Connection via RS-422 programming cable (SC-09).
• Q3: Can I expand I/O beyond 32 points?
  Yes. The base unit supports up to 8 expansion modules. Maximum total I/O can reach 256 points when using additional FX2N extension units.
• Q4: What is the warranty and shipping policy?
  ✔ 12-month warranty covers manufacturing defects.
  ✔ Orders ship within 12–24 hours on business days.
  ✔ Worldwide delivery via FedEx, UPS, DHL with tracking number.
• Q5: How to select between transistor and relay output models?
  Choose relay output (MR) like this model when switching AC loads or when isolation is needed. Transistor models (MT) are better for high-speed pulse output and DC loads.

🛠️ Selection Guide & Pro Tips

• ▪ Best for: Small machines with mixed AC/DC loads. Relay outputs tolerate voltage spikes.
• ▪ Memory backup: Optional FX2N-32BL battery retains data for up to 5 years.
• ▪ Installation tip: Use surge suppressors for inductive loads to extend relay life.
• ▪ Compatibility: Works with legacy FX2N analog, temperature, and positioning modules – easy retrofit.
