Product Overview
Honeywell C7061A1020 is an ultraviolet flame detector with oscillating shutter. It senses UV radiation from gas, oil, or other fuel combustion. This detector works with R7861 dynamic self-checking amplifiers. It provides reliable flame monitoring for industrial burners.
Key Features
- Dynamic self-checking with oscillating shutter
- Voltage: 120 or 230 V AC (50/60 Hz)
- Temperature range: -40°C to +79°C
- NEMA 4 rated enclosure
- Field replaceable UV sensing tube and quartz window
- Flexible mounting: Horizontal, vertical, or any angle
- Heat block built into mounting flange
- Two detectors can wire in parallel for redundancy
Technical Specifications (Hierarchical)
- General
- Brand: Honeywell
- Model: C7061A1020
- Type: Ultraviolet Flame Detector with Shutter
- Used with: R7861 Dynamic Self-Check Amplifiers
- Electrical
- Supply voltage: 120 or 230 V AC
- Frequency: 50/60 Hz
- Electrical connections: Terminal block
- Mechanical
- Dimensions: 133 mm diameter x 183 mm long
- Mounting: 3/4 inch NPT
- Mounting orientation: Horizontal, vertical, or any angle
- Shipping weight: 3 kg
- Environmental
- Ambient temperature: -40°C to +79°C
- NEMA rating: NEMA 4
- Viewing window: Quartz (field replaceable)
- Approvals
- Swiss RE: Acceptable
- Compatibility Notes
- C7061A1038/A1046: 5-pin Brad Harrison connector (not supplied)
- C7061E: NEMA 4, 20 psi window
- C7061F: Explosion-proof, 100 psi window
Expert Review
“C7061A1020 offers reliable UV flame detection for industrial burners. The oscillating shutter provides dynamic self-checking for safety. Wide temperature range suits harsh environments. We recommend it for gas and oil-fired combustion systems.”
Manager’s Insight
“This detector simplifies burner management with self-checking functionality. The replaceable UV tube reduces maintenance costs. NEMA 4 rating ensures durability. With 12-month warranty and fast shipping, it is a solid investment for plant safety.”
Applications & Compatible Devices
- Burners: Gas-fired burners, oil-fired burners
- Amplifiers: Honeywell R7861 Dynamic Self-Check Amplifiers
- Industries: Power generation, chemical plants, refineries
- Use cases: Flame monitoring, burner management systems
Installation & Maintenance
- Mounting: 3/4 inch NPT fitting, any orientation
- Alignment: Faceplate alignment with locating reference points
- Wiring: Color-coded leadwires for rapid installation
- Replacement: Field replaceable UV sensing tube and quartz window
- Redundancy: Wire two detectors in parallel for nuisance shutdown reduction
Frequently Asked Questions
- Q: What does the oscillating shutter do?
It interrupts UV radiation to check the sensor tube function dynamically. - Q: Can I use this detector with other amplifiers?
No. It works specifically with R7861 Dynamic Self-Check Amplifiers. - Q: What is the maximum ambient temperature?
+79°C. Minimum is -40°C. - Q: Is the UV tube replaceable?
Yes. You can replace it in the field without special tools. - Q: What NEMA rating does this model have?
NEMA 4. (C7061F offers explosion-proof for hazardous areas.)
Experience-based Q&A
- Q: The detector shows no flame signal. What should I check?
Verify the UV tube and window are clean. Check alignment to the flame. - Q: Can I mount this detector upside down?
Yes. Mounting orientation is flexible (horizontal, vertical, or any angle). - Q: How to reduce nuisance shutdowns?
Wire two detectors in parallel for redundancy in difficult sighting applications.
Selection Guide
- For standard industrial burners, choose C7061A1020 with NEMA 4.
- For hazardous atmospheres, select C7061F (explosion-proof).
- For high pressure viewing, use C7061E (100 psi window).
- For quick wiring, color-coded leadwires simplify installation.
- For redundant systems, order two detectors and wire in parallel.
Comparison with Similar Models
- C7061A1020 – Standard UV detector, NEMA 4, 120/230V.
- C7061E – NEMA 4, 20 psi viewing window.
- C7061F – Explosion-proof housing, 100 psi window.
Package Contents
- C7061A1020 UV flame detector (1 unit)
- Mounting flange with heat block
- UV sensing tube (installed)
- Quartz viewing window (installed)
- Quick start guide
- Warranty card (12 months)
