Bently Nevada 200157-13-05 Enveloping Trendmaster Pro Accelerometer
Product Summary
The 200157-13-05 accelerometer by Bently Nevada provides reliable envelope monitoring for early detection of bearing faults and cavitation. Designed for harsh industrial settings, it offers precise acceleration-to-velocity conversion.
Model Details
- Model Number: 200157
- Mounting Stud: 13 (3/8-24 to 5/16-18 UNC, 3/4 inch hex)
- Approvals: 05 (CSA, ATEX, IECEx certified)
Key Technical Specs
- Sensitivity: 10.2 mV/(m/s²) (100 mV/g) at 80 Hz
- Measurement Range: ±245 m/s² (±25 g)
- Frequency Range: 10–10,000 Hz (600–600,000 cpm)
- Output Bias Voltage: +2.5 Vdc ± 0.23
- Excitation Voltage: 4.7–5.5 Vdc
- Current: <800 µA
- Resonant Frequency: >20 kHz
- Linearity: ±2% (1 to 10 g peak)
- Transverse Sensitivity: ≤7%
- Settling Time: ≤300 ms
Installation Guide
- Use 5/16-18 UNC stud adapter supplied
- Follow mounting torque guidelines for secure fit
- Allow 24-hour curing time when adhesive is used
Applications & Solutions
- Detect bearing wear in large motors
- Identify cavitation early in fluid pumps
- Monitor gearboxes in mining equipment
- Improve uptime by early fault detection
