Product details
Harsh Environment Vibration Probe
Engineered for demanding sites, the Bently Nevada 330709-000-030-50-12-05 combines an ultra-short 30mm body with a sealed FluidLoc cable. This probe thrives where space is tight and conditions are wet or oily. It’s a premium choice in the 3300 XL series.
Key Advantages
- Extreme Space Saver: Shortest 30mm case for minimal clearance needs.
- Sealed Against Moisture: FluidLoc cable protects in damp, wash-down areas.
- Universal Compatibility: Standard ClickLoc connector for easy integration.
- Built for Industry: Stainless steel and PPS ensure long service life.
- Fully Certified: Manufactured with multiple international safety approvals.
Product Specifications
- Brand: Bently Nevada
- Product Line: 3300 XL 11 mm Proximity Probes
- Full Item Code: 330709-000-030-50-12-05
- 330709 – 11mm Probe, M16x1.5 Thread, No Armor
- 000 – Unthreaded Length: 0 mm
- 030 – Overall Case: 30 mm
- 50 – Cable Length: 5.0 metres
- 12 – Connector/Cable: ClickLoc with FluidLoc
- 05 – Agency Certs: Multiple Approvals
- Performance Data
- Electrical Resistance (5m): 7.2 ± 0.8 Ohms
- Cable Build: 75 Ω Triaxial, FEP Insulation
- Minimum Target: 30.5 mm flat surface diameter
- Recommended Shaft: Minimum 152 mm diameter
- Mechanical Details
- Case: AISI 304 Stainless Steel
- Tip: Polyphenylene Sulfide (PPS)
- Mounting Thread: M16 x 1.5
- Installation Torque: 21.1 N•m (Recommended)
- Connector Torque: Finger tight only
- Cable Bend Limit: Minimum 25.4 mm radius
- Environmental Ratings
- Operating Temp: -52°C to +177°C
- Seal Care: Avoid prolonged exposure below -34°C.
- Safety Class: Compliant with EPL Ga, Gc, Dc requirements.
Installation Notes
- Confirm the mounting hole provides full thread engagement.
- Torque the probe case to 21.1 N•m for a secure fit.
- Connect the FluidLoc cable by hand until snug.
- Plan cable routing to maintain bend radius.
- Ensure the target surface is clean, conductive, and sized correctly.
System Integration
The 330709-000-030-50-12-05 is designed for Bently Nevada 3300 XL monitoring systems. Note: This 5-meter probe requires pairing with a 5-meter Proximitor sensor. For monitoring smaller components, see the 3300 XL 8mm Proximity Probe.
Purchase Details
- Approvals: This model ships with multiple agency certifications.
- Included: One proximity probe with FluidLoc cable.
- Warranty: Protected by a standard 12-month warranty.
- Shipping: Available via FedEx, UPS, and DHL for fast delivery.
FAQs
Technical Features
- What is the key benefit of the “12” cable option?
Option “12” provides a FluidLoc cable. This has a special seal at the connector to block moisture and oil ingress, greatly increasing reliability in wet environments. - How does the 30mm case length affect installation?
The 330709-000-030-50-12-05 needs only about 30mm of space behind the mounting surface. This is critical on thin machine housings or where other components are close behind.
Application & Selection
- Is this the right probe for a food & beverage plant?
Yes. The stainless steel body, PPS tip, and sealed FluidLoc cable of the 330709-000-030-50-12-05 can withstand wash-downs and humid conditions common in such facilities. - Can I use this 5m probe with a 9m extension?
No. You must not add extensions. The system calibration is for the specific probe cable length. Use a probe with the total cable length you need.
Ordering & Support
- What is the lead time for this specific model?
The 330709-000-030-50-12-05 is typically in stock or has short lead times. Contact us for the most current availability and delivery estimate to your location.
