Reverse Mount 11mm Probe for Specialized Monitoring
Introducing the Bently Nevada 3300 XL 11mm Reverse Mount Probe, model 330705-02-18-10-00-00. This sensor is engineered for applications where space behind the mounting surface is limited. Its unique reverse mount design and larger 11mm diameter offer superior durability and installation flexibility. Perfect for monitoring thrust position and vibration in confined machinery spaces.
Configuration Tree: Model 330705-02-18-10-00-00
- 330705 – Base Model
- 3300 XL 11mm Reverse Mount Probe
- -02 – Unthreaded Length
- 0.2 inches
- -18 – Overall Case Length
- 1.8 inches
- -10 – Cable Length
- 1.0 meter (3.3 feet)
- -00 – Connector Type
- Miniature ClickLoc Coaxial
- -00 – Agency Approval
- Not Required
Technical Specifications
- Brand: Bently Nevada
- Series: 3300 XL Monitoring System
- Probe Type: 11mm Reverse Mount Proximity
- Case Material: AISI 304 Stainless Steel
- Tip Material: PPS Plastic
- Cable Type: 75 Ω Triaxial, FEP Insulated
- Probe Resistance: 5.9 Ω ± 0.5 Ω
- Temperature Range: -51°C to +177°C (-60°F to +351°F)
- Pressure Seal: Viton O-Ring
- Minimum Bend Radius: 25.4 mm (1.0 inch)
- Connector Torque: Finger tight (0.565 N•m max)
- Weight: 0.07 Kg
Key Features & Benefits
- Reverse Mount Design: Ideal for limited clearance behind mounting surface
- Larger 11mm Diameter: Enhanced durability in harsh environments
- High-Temperature Cable: FEP insulation withstands extreme temperatures
- Triaxial Construction: Superior noise immunity and signal integrity
- Simple Installation: Easy connector mating with finger-tight torque
Installation Guide
- Mount from the back side of the installation surface
- Ensure minimum 1.0 inch bend radius for cable routing
- Connect ClickLoc connector finger-tight (do not overtighten)
- Maintain proper cable strain relief
- Avoid installation below -34°C to preserve pressure seal
Ordering Information
- Package Includes: One 11mm reverse mount probe with 1m cable
- Warranty: 12-month manufacturer warranty
- Shipping: Available via FedEx, UPS, DHL worldwide
- Lead Time: Usually ships within 2-3 business days
Expert FAQ
What is a reverse mount probe and when should I use it?
A reverse mount probe installs from behind the mounting surface. Use it when there’s insufficient space in front of the machine for standard probe installation.
How does the 11mm diameter compare to standard 8mm probes?
The 11mm probe offers greater physical strength and more epoxy around the coil. This makes it more resistant to impact and vibration in demanding applications.
Can this probe be used in hazardous areas?
This specific model (330705-02-18-10-00-00) has no agency approvals. For hazardous areas, consult with us for appropriate intrinsically safe configurations.
What maintenance does the FEP cable require?
FEP cable is highly durable and requires minimal maintenance. Regular visual inspection for cuts or abrasion is recommended during routine maintenance checks.
How do I ensure proper signal quality with triaxial cable?
Use proper grounding techniques and maintain the cable shield integrity. Follow Bently Nevada’s installation guidelines for optimal performance.
Technical Support & Contact
Need help selecting the right probe? Our technical team is ready to assist:
Email: sales@powergearx.com
WhatsApp: +86 18030005825
Certification & Compliance
Available with various hazardous area certifications including:
• Class I, Zone 0: AEx/Ex ia IIC T4/T5 Ga
• Class I, Zone 2: AEx/Ex nA IIC T4/T5 Gc
• Class I, Division 2, Groups A, B, C, D
