Name: Bently Nevada 330704-010-050-10-01-05 Proximity Probe | Multi-Certified
SKU: 330704-010-050-10-01-05
Availability: InStock

Product details

Precision-Engineered for Specific Mounting: 330704-010-050-10-01-05

This Bently Nevada 3300 XL probe offers a precise mounting configuration. It features a 10 mm unthreaded section at the tip. The probe is fully armored and multi-certified. It is brand new and original, complete with a 12-month factory warranty.

Distinctive Design Advantages

Precise Unthreaded Tip: 10 mm smooth section for exact positioning in the mounting hole.
Global Project Ready: Holds Multiple Approvals (-05) for worldwide compliance.
Armored Durability: Full stainless steel armor protects the cable from physical harm.
Protected Connection: Includes a connector protector for the ClickLoc interface.
Standard Cable Length: 1.0-meter cable for typical connection setups.

Detailed Technical Data

Product & Compliance Information

Brand: Bently Nevada
Exact Part Number: 330704-010-050-10-01-05
Series & Type: 3300 XL 11 mm Armored Proximity Probe
Compliance: Multiple Agency Approvals (-05)

Mechanical Configuration

Mounting Thread: M14 x 1.5 mm
Unthreaded Length: 10 mm (at probe tip)
Overall Case Length: 50.0 mm
Cable Length: 1.0 meter (3.3 ft)
Armor: Yes (Stainless Steel)
Connector: ClickLoc with Protector (-01)

Electrical Specifications

Probe DC Resistance: 5.9 ± 0.5 Ohms
Cable Construction: 75-ohm Triaxial, Standard FEP.
EMI Performance: Highly resistant to magnetic interference (data provided).

Environmental & Operational Limits

Operating Temperature: -52°C to +177°C (-62°F to +351°F)
Key Materials: 304 SST Case/Armor, PPS Tip, Viton Seal.
Mounting Torque: Apply 21.1 N·m (187 in-lb).
Low-Temp Note: Continuous operation below -34°C (-29°F) not advised for seal longevity.

Package Contents & Guarantee

One (1) Bently Nevada 330704-010-050-10-01-05 proximity probe.
All original factory packaging, protector, and certification documents.
12-Month Manufacturer Warranty.
Express worldwide shipping via FedEx, UPS, or DHL.

Application & Selection Note

This probe is ideal when the mounting hole is precisely bored. The 10mm unthreaded section acts as a pilot, ensuring perfect alignment before the threads engage. Choose this model for applications requiring precise mechanical positioning and the highest level of certification for global projects.

Expert FAQs

Q: What is the purpose of the “010” (10 mm) unthreaded length option?

A> The 10 mm unthreaded section at the probe’s tip serves as a guiding pilot. It helps center the probe perfectly in the mounting hole before the threads start. This ensures accurate alignment and prevents cross-threading.

Q: Does the unthreaded section affect the electrical gap setting?

A> No. The unthreaded length is part of the probe’s case. The actual sensing tip is at the very end. You still set the gap from the tip of the probe to the target, following the standard 1.0 mm (40 mil) recommendation.

Q: Can I use this probe in a hole that is completely threaded (no pilot)?

A> It is not ideal. The unthreaded pilot section is designed to fit into a smooth portion of the mounting hole. If the hole is fully threaded, the probe may not align easily and could be damaged during installation.

Q: What specific certifications are included in the “Multiple Approvals (-05)”?

A> The exact certifications vary. They commonly include major standards like ATEX, IECEx, and UL or location-specific ones. The factory documentation shipped with the probe will list all applicable certifications for the 330704-010-050-10-01-05.

Q: How do I place an order and what are the shipping costs?

A> You can order directly on our site. Shipping costs are calculated at checkout based on your location and chosen carrier (DHL, FedEx, UPS). For large or urgent orders, contact us for a dedicated quote and fastest shipping arrangement.

Need help interpreting certifications or verifying mechanical fit? Our technical sales team is ready to assist.
