Product details
Versatile & Protected Industrial Probe
The Bently Nevada 330104-02-12-10-01-00 offers a balanced design with a 20mm unthreaded section and connector protection. This configuration provides mounting flexibility and physical durability, making it a reliable choice for continuous vibration monitoring in demanding environments.
Model Number Architecture
Full Part Number: 330104-02-12-10-01-00
- Series Identifier 330104: 3300 XL 8mm Armored Probe
- Option -02: Unthreaded Length = 20mm
- Option -12: Overall Case = 120mm
- Option -10: Cable Length = 1.0 Meter
- Option -01: Connector = ClickLoc with Protector
- Option -00: Agency Approval = Standard
Fundamental Specifications
- Primary Function: Vibration and Position Sensing
- Effective Range: 2.0 mm Linear Displacement
- Installation Target: 1.27 mm Gap (-9 Vdc)
- Material Composition: PPS Tip, SST Case (M10x1)
- Temperature Operating Range: -52°C to +177°C
- Environmental Seal: Viton® O-Ring, Humidity Resistant
- Electrical Data: 1.0m Integrated Cable, 7.59 Ω Resistance
- System Wiring: Supports runs up to 305m with shielded cable.
Design Benefits
- Adaptive Mounting: 20mm smooth shank aids alignment in adapters.
- Enhanced Durability: Connector protector prevents damage in crowded panels.
- Practical Length: 120mm case offers a secure grip for installation.
- Wide Compatibility: Works seamlessly with standard 3300 XL systems.
- Proven Stability: Maintains calibration in harsh industrial conditions.
Safety & Application Notes
- Can be integrated into hazardous area systems with proper barriers.
- Ideal for pumps, compressors, and fans in general industrial settings.
- Follow standard procedures for gap setting and wiring.
Purchasing & Support
- Package Contents: One fully assembled probe.
- Warranty Period: Protected by a 12-month manufacturer warranty.
- Delivery Service: Shipped globally via FedEx, UPS, or DHL couriers.
Expert FAQ & Selection Tips
What is a typical use for the 20mm unthreaded section?
The 20mm smooth area (option 02) is useful when using a locknut or mounting the probe in a drilled-through bracket. It provides a precise surface for clamping.
Is the 120mm case length a common size?
Yes, 120mm is a popular and versatile length. It provides enough material for secure installation without being too bulky for most applications.
Why choose a model without agency approvals (option 00)?
Choose the 330104-02-12-10-01-00 for standard industrial plants where CSA/ATEX certifications are not mandated by safety codes. It is a cost-effective solution.
How does the connector protector help in the field?
The plastic guard prevents the delicate connector pins from being bent or shorted if the cable is accidentally pulled or impacted during maintenance.
What are the key factors when selecting this model?
Confirm the 20mm unthreaded section meets your mounting needs. The connector protector is valuable in high-traffic areas. Ensure the 1.0m cable suits your cabinet layout.
