Product details
Essential Product Information
This is an original Bently Nevada 330104-00-03-10-01-00 proximity probe. It is an 8mm sensor from the 3300 XL series. It measures machinery vibration and position. This probe protects turbines, compressors, and motors. It ensures reliable operation and safety.
Core Technical Specifications
- Brand & Series: Bently Nevada 3300 XL
- Full Model: 330104-00-03-10-01-00
- Key Parameters
- Measurement Range: 0.25 to 2.3 mm (Linear)
- Recommended Gap: 1.27 mm (for -9 Vdc)
- Frequency Response: Suitable for most machinery speeds
- Temperature Range: -52°C to +177°C (Operating)
- Physical Construction
- Probe Tip: Durable PPS Plastic
- Probe Case: AISI 303/304 Stainless Steel
- Thread Size: M10 x 1.0 metric
- Cable & Connector: 1.0 meter with ClickLoc
- Environmental & Safety
- Hazardous Area Certified: Yes (ATEX, IECEx)
- Sealing: Viton® O-ring for internal protection
- Humidity Resistant: Minimal performance change
Easy Installation & Setup
- Thread the probe into an M10 x 1 mounting hole.
- Do not engage threads more than 15 mm.
- Connect the ClickLoc connector to the proximitor.
- Set the air gap for about -9 Vdc output.
- Use shielded cable for best noise immunity.
Compatibility & Integration
This probe works with Bently Nevada 3300 XL Proximitor Sensors. It connects to many vibration monitors. It is perfect for both new installations and upgrades. Use it for API 670 compliant systems.
What You Receive
- One (1) Bently Nevada 330104-00-03-10-01-00 Probe.
- Miniature ClickLoc connector with protector.
- Full 12-month product warranty.
- Shipped via FedEx, UPS, or DHL for quick delivery.
Frequently Asked Questions
Product Selection Guide
How do I confirm this is the right probe for my machine?
Check your existing sensor part number or machine manual. Ensure you need an 8mm diameter probe with M10 thread. Contact us if you are unsure.
What is the difference between standard and extended temperature probes?
The standard probe is for most applications. The extended version supports hotter environments near the cable.
Installation & Performance
Why is the recommended gap -9 Vdc?
This setting places the target in the middle of the probe’s linear range. It provides the best measurement accuracy for vibration.
My cable run is very long. Will this cause issues?
You can use up to 305 meters of cable. Very long runs may reduce high-frequency signal quality. Use good quality shielded cable.
Maintenance & Troubleshooting
How often should I check the probe gap?
Check during annual machine maintenance. Also check if vibration readings seem unusual or drift over time.
The probe was in cold storage. Can I use it immediately?
Let it warm to above -30°C before installing. Sudden temperature change can damage the seal.
Get Expert Support
Need help with your order or application? Our technical sales team is ready to assist.
Email: sales@powergearx.com
Phone/WhatsApp: +86 18030005825
