Product details
Special Configuration for Challenging Environments
This Bently Nevada 330103-06-15-10-12-CN probe is built for durability. It combines a FluidLoc cable with a unique 60mm unthreaded section. It suits complex mounting needs in wet or oily areas.
Technical Configuration & Details
- Product Identification
- Brand: Bently Nevada
- Complete Model: 330103-06-15-10-12-CN
- Product Family: 3300 XL Series
- Probe Type: 8mm Proximity Sensor
- Key Performance Metrics
- Linear Range: 2.0 mm (80 mils)
- Target Gap Voltage: -9 Vdc (for 1.27 mm gap)
- Electrical Spec: Resistance = 7.59 Ω ± 0.50 Ω
- System Wiring: Up to 305 meters maximum.
- Physical Build & Options
- Case Material: 303/304 Stainless Steel
- Tip Material: PPS (Polyphenylene Sulfide)
- Sealing: Viton® O-Ring
- Mounting Thread: M10 x 1.0
- Operating Temp: -52°C to +177°C
- Custom Configuration Explained
- Unthreaded Length (06): 60 mm smooth section
- Case Length (15): 150 mm total
- Cable Length (10): 1.0 meter
- Cable Type (12): FluidLoc (oil-resistant)
- Approval (CN): Country-Specific on request
Practical FAQs & Selection Help
Q: What is the purpose of the 60mm unthreaded section?
A: The unthreaded section allows the probe to pass through a mounting bracket or sleeve. You then secure it with a locknut on the threaded part. This offers flexible mounting.
Q: When should I choose the “FluidLoc” cable option?
A: Always choose FluidLoc for pumps, compressors, or gearboxes. It protects against oil spray, coolant, and chemical splashes. It extends cable life in harsh conditions.
Q: What does “Country Specific (CN)” approval mean?
A: This means the probe can be supplied with certifications for specific countries. Common examples include NEPSI for China or INMETRO for Brazil. Inquire with your order.
Q: Is the 150mm case length a standard size?
A: The 150mm length is less common. It is used for deeper mounting applications. Please verify your mechanical clearance before ordering this 330103-06-15-10-12-CN model.
Q: How do I ensure I get the right probe for my project?
A: Confirm the cable type, length, and case dimensions match your drawing. All our probes include a 12-month quality guarantee. We offer express delivery with DHL, FedEx, and UPS.
Contact for Custom Certification & Orders
Need a specific country approval or have technical questions? Our team can help.
Email us at: sales@powergearx.com
Chat on WhatsApp: +86 18030005825
