Bently Nevada 330103-03-08-10-01-00 in Stock | 8mm Proximity Probe

Bently Nevada 3300 XL 8mm Proximity Probe

This is the 330103-03-08-10-01-00 model. It is a reliable vibration sensor for industrial machines. Its design protects critical equipment. This probe ensures accurate monitoring in tough conditions.

Product Configuration: 330103-03-08-10-01-00

• Base Model: 330103 (3300 XL 8mm Probe, M10x1 thread, no armor)
• Unthreaded Section [03]: 30 mm. Provides a smooth shaft for mounting.
• Total Case Length [08]: 80 mm. A longer body for specific installations.
• Cable Length [10]: 1.0 meter (3.3 feet) attached cable.
• Connector Type [01]: ClickLoc connector with a protective cover.
• Certifications [00]: Standard industrial model. No hazardous area approvals.

Technical Specifications

• Manufacturer & Code: Bently Nevada 330103-03-08-10-01-00
• Product Line: 3300 XL Series Vibration Probe
• Key Performance Metrics:
  • Measurement Range: 2.0 mm linear displacement.
  • Recommended Gap: 1.27 mm (50 mils) for -9 Vdc output.
  • Electrical Resistance: 7.59 Ω ± 0.50 Ω (for 1m cable).
  • Frequency Response: Stable for most machinery speeds.
• Construction & Materials:
  • Probe Body: Robust AISI 303/304 Stainless Steel.
  • Sensing Tip: Durable Polyphenylene Sulfide (PPS).
  • Environmental Seal: Viton® O-ring.
• Operating Environment:
  • Temperature Range: -52°C to +177°C (Standard operation).
  • Extended Range: Tip can withstand up to +218°C.
  • Humidity Resistance: Minimal signal drift in high humidity.
• Installation Notes:
  • Mounting: M10 x 1 thread. Maximum 15 mm thread engagement.
  • Wiring: Compatible with standard shielded triad cable.
  • System Pairing: Works with Bently Nevada 3300 XL Proximitors.

What’s Included & Support

• Package Contents: One proximity probe with 1m cable and connector protector.
• Warranty Coverage: Full 12-month warranty for peace of mind.
• Shipping Options: Reliable global delivery via FedEx, UPS, or DHL.

Expert FAQs for Smart Buyers

Model Specifics

Q: What is the benefit of the 30mm unthreaded length?

A: The 30mm smooth section (code ’03’) allows the probe to pass through a mounting bushing before the threads engage. This aids alignment.

Q: The case is 80mm long. When is this needed?

A: An 80mm case (code ’08’) is used when the mounting point is far from the target surface, like on some large gearboxes or turbines.

Usage & Compatibility

Q: Does this model have safety certifications?

A: No. The 330103-03-08-10-01-00 has approval code ’00’. It is for standard industrial areas, not certified hazardous locations.

Q: Can I use this in very cold environments?

A: It works down to -52°C. But, exposing it below -34°C may damage the internal seal over time.

Ordering Process

Q: What is your warranty and how do you ship?

A: We provide a solid 12-month warranty. Your order ships quickly using major carriers like DHL, FedEx, or UPS.

Get in Touch for Your Bently Nevada Needs

Interested in the 330103-03-08-10-01-00 or need a quote? Contact our team today.
