Product details
Product Profile: Bently Nevada 3300 XL Probe
Introducing the Bently Nevada 330103-00-16-10-12-05. This 8mm proximity probe is built for precise machinery health monitoring. It features a full-threaded design and a rugged FluidLoc cable for challenging environments.
Product Anatomy: Understanding Your Model Code
- Core Identifier: 330103 (8mm Probe, M10x1, No Armor)
- Configuration Details:
- -00: Unthreaded Section = 0 mm (Fully Threaded)
- -16: Case Length = 160 mm
- -10: Cable Length = 1.0 meter (3.3 feet)
- -12: Connection = ClickLoc with FluidLoc Cable
- -05: Certification = CSA, ATEX, IECEx
Key Technical Data
- Product: 330103-00-16-10-12-05 by Bently Nevada
- Function: Vibration and Position Measurement
- Linear Range: 0.25 mm to 2.3 mm from target
- Optimal Gap: Set to 1.27 mm (50 mils)
- Electrical: 7.59 Ω Resistance (±0.50 Ω)
- Construction: Stainless Steel Case, PPS Tip
- Seal: Viton® O-Ring (Pressure Differential)
- Temperature: Operates from -52°C to +177°C
- Cable: 1.0m FluidLoc, ClickLoc Connector
- Mounting: M10 x 1 Thread (Full 160mm Length)
- Safety: Approved for Hazardous Locations
FAQ: Your Questions Answered
About This Specific Model
- What does “Unthreaded Length: 00” mean for installation?
- It means the entire 160mm case is threaded (M10x1). This is ideal for mounting directly through thick housings or brackets without needing an unthreaded shoulder.
Features & Applications
- What is the benefit of the FluidLoc cable (option -12)?
- The FluidLoc cable has a special jacket that resists oils, coolants, and chemicals. It is perfect for wet or wash-down areas in industrial plants.
- Can this fully threaded probe be used in high-temperature applications?
- Yes. The probe tip handles up to 218°C. The all-metal, threaded body provides excellent heat dissipation in hot environments.
Ordering & Support
- Is this probe ready for use in explosive atmospheres?
- Yes. The -05 suffix confirms ATEX, IECEx, and CSA approvals. You can use it in classified areas with proper intrinsic safety barriers.
- What support comes with my order?
- Your order includes a 12-month product warranty. We ship quickly worldwide using FedEx, UPS, or DHL.
Ready to Order?
The 330103-00-16-10-12-05 is perfect for heavy-duty, wet, or hazardous areas. Choose it for its full-threaded strength and FluidLoc cable. Need a different size? Contact us for options.
