Bently Nevada 330102-00-48-05-02-00 | 4.8-Inch Armored 3300 XL Probe

Durable 4.8-Inch Armored Monitoring Solution

Designed for reliability in demanding environments, this 3300 XL 8mm Proximity Probe, model 330102-00-48-05-02-00, delivers robust vibration sensing with its 4.8-inch armored construction and 0.5-meter cable. It’s built for standard industrial applications where equipment protection and signal integrity are essential.

Detailed Model Configuration Guide

Your probe’s specifications are encoded in its part number. Here’s what each segment means:

• Full Product Code: 330102-00-48-05-02-00
  • 330102 – Armored Probe Core with 3/8-24 UNF Thread
    00 →

    Unthreaded Section: 0.0 inches

    48 →

    Case Length: 4.8 inches (122 mm)

    05 →

    Cable Length: 0.5 meter (1.6 feet)

    02 →

    Connector: Standard ClickLoc Type

    00 →

    Agency Approval: Not Required

Performance & Engineering Specifications

• Mechanical Build Quality
  • Case: 4.8-inch armored AISI 303/304 Stainless Steel
  • Thread: 3/8-24 UNF, maximum engagement 0.563 inches
  • Tip: Wear-resistant Polyphenylene Sulfide (PPS)
  • Sealing: Viton® O-ring for basic environmental protection
• Measurement Capabilities
  • Linear Range: 2.0 mm (80 mils) total measurement span
  • Optimal Gap Setting: 1.27 mm (50 mils) producing -9 Vdc output
  • Signal Output: Approximately -1 to -17 Vdc across linear range
  • Electrical Resistance: 7.45 Ω ± 0.50 Ω for 0.5m cable
• Environmental Resilience
  • Temperature Range: -52°C to +177°C (-62°F to +350°F)
  • Humidity Tolerance: <3% change in ASF at 93% relative humidity
  • Field Wiring: Compatible with standard 3-conductor shielded cable
  • Maximum Cable Run: 305 meters to monitor

Professional Application Guidance

Configuration & Selection Questions

• What types of machinery benefit most from this 4.8-inch armored design?
• This probe excels in medium-duty industrial applications including pumps, fans, and mid-sized compressors where vibration monitoring is needed and cable protection is important, but hazardous area certifications aren’t required.
• How does the 0.5-meter cable length affect installation planning?
• The shorter cable works best when the proximitor can be mounted within 1.6 feet of the probe. For longer distances, plan to use appropriate shielded extension cable while staying within the 305-meter total system limit.

Installation & Maintenance

• What’s the proper procedure for installing the armored section?
• Secure the armored cable within 6 inches of the probe body using suitable clamps. Maintain minimum bend radius to prevent stress concentration. The armor should be properly grounded according to your facility’s electrical standards.
• Are there special considerations for temperature extremes?
• While rated to -52°C, avoid sustained operation below -34°C to prevent premature seal failure. In high-temperature applications above 150°C, ensure adequate clearance from heat sources and consider the extended temperature range options if needed.

Technical Support & Procurement

• What documentation accompanies non-certified probes?
• Standard probes include manufacturer’s data sheets and installation guidelines. For applications requiring pressure testing or custom documentation, contact our support team to coordinate with Bently Nevada’s custom design department.
• How quickly can I receive this model?
• Standard configurations typically ship within 24-48 hours. We offer multiple shipping options including FedEx, UPS, and DHL for urgent requirements. All products carry a 12-month warranty.

Ordering Information & Service Commitment

• Complete Package Contents:
  • One factory-new Bently Nevada 3300 XL 8mm Proximity Probe
  • Model: 330102-00-48-05-02-00
  • Pre-installed ClickLoc connector
  • Manufacturer’s technical documentation
• Quality Assurance & Warranty:
  • Full 12-month manufacturer’s warranty against defects
  • Original Bently Nevada quality with factory calibration
  • Performance tested to published specifications
• Shipping & Logistics:
  • Global delivery via FedEx, UPS, and DHL networks
  • Real-time tracking provided for all shipments
  • Export documentation available for international orders
