Allen-Bradley 1762-OB32T MicroLogix Solid State Output Module

Allen-Bradley 1762-OB32T MicroLogix Output Module

The Allen-Bradley 1762-OB32T expands your MicroLogix system with high-density output capability. This Rockwell Automation module provides thirty-two solid-state outputs in a compact form factor. It delivers reliable performance for various industrial automation applications.

Detailed Technical Specifications

• Brand: Allen-Bradley / Rockwell Automation
• Model: 1762-OB32T (Full Catalog Number: 1762-OB32T)
• Output Type: Solid State Source Output
• Number of Outputs: 32 channels
• Output Groups: 2 isolated groups (16 channels each)
• Output Voltage: 10.2-26.4VDC (Nominal 24VDC)
• Current Rating: 0.5A per point @ 60°C
• Group Current: 2.0A per group @ 60°C
• Module Current: 4.0A total @ 60°C
• Surge Current: 2.0A for 10ms (repeatable every 2s)
• Isolation Rating: 1200V AC for 2 seconds
• Response Time: 0.5ms ON, 4.0ms OFF
• Wire Size: 22-26 AWG
• Heat Dissipation: 3.4 Watts

Packaging List

• One (1) Allen-Bradley 1762-OB32T output module
• Installation documentation and mounting hardware
• We ship via FedEx, UPS, or DHL for reliable delivery

Frequently Asked Questions (FAQ)

• What loads can this module drive?
  It can drive indicating lights, solenoids, and small DC motors up to 0.5A per point.
• How many output groups does it have?
  The module has two electrically isolated groups of 16 outputs each.
• What is the isolation voltage rating?
  It provides 1200V AC isolation for enhanced safety and noise immunity.

The Allen-Bradley 1762-OB32T delivers reliable output expansion for MicroLogix systems. Rockwell Automation designed this module for industrial durability and performance.
