Name: 6ES7422-7BL00-0AB0 Siemens S7-400 Output Module | 32-Channel 24V
SKU: 6ES7422-7BL00-0AB0
Price: 234.00 USD
Availability: InStock

Product details

Product Description

Siemens 6ES7422-7BL00-0AB0 – digital output module for SIMATIC S7-400 systems
- 32 optically isolated output channels
- Rated voltage 24V DC, current 0.5A per point
- Fast switching with 0.15 ms output delay
- Built-in diagnostics for easier troubleshooting

Technical Specifications

Brand & Model
- Brand: Siemens
- Model: 6ES7422-7BL00-0AB0
- Product type: SM 422 Digital Output Module
- Series: SIMATIC S7-400
Supply & Power
- Load voltage L+: 24V DC (range 20.4-28.8V)
- Input current from L+: 120 mA max (no load)
- Backplane bus current: 200 mA at 5V DC
- Power loss: 8 W max
Output Channels
- 32 digital outputs (binary)
- Signal “1” voltage: L+ minus 0.8V min
- Rated output current: 0.5 A per channel
- Signal “1” current range: 5 mA to 0.6 A (0-60°C)
- Signal “0” residual current: 0.5 mA max
- Lamp load capacity: 5 W max
Switching Performance
- Output delay: 0.15 ms (signal transition)
- Switching frequency (resistive load): 100 Hz max
- Switching frequency (inductive load): 2 Hz max
- Inductive shutdown voltage: limited to L+ (-45V)
Group Current & Cable
- Group current: 2 A max per 8-channel group (60°C)
- Shielded cable length: 1000 m max
- Unshielded cable length: 600 m max
Diagnostics & Alarms
- Diagnostic alarm: Yes (parameterizable)
- Diagnostics: internal and external fault detection
- Status indicators for each channel
Isolation & Protection
- Galvanic isolation: groups of 8 channels
- Isolation between channels and backplane bus: Yes
- Test voltage: 500V DC
Dimensions & Weight
- Width: 25 mm (0.98 in)
- Height: 290 mm (11.42 in)
- Depth: 210 mm (8.27 in)
- Weight: 0.6 kg (1.32 lbs)

Installation & Wiring

Mounting
- Install in S7-400 rack (UR1, UR2, or similar)
- Use slot number 4-11 for this module
- Secure with fixing screws at top and bottom
Wiring tips
- Use shielded cable for critical signal paths
- Keep output wires away from AC power lines
- Group current limit: 2A per 8-channel block
- Do not exceed 0.6A per individual output

Compatibility

Works with
- Siemens SIMATIC S7-400 CPUs (all versions)
- ET 200M distributed I/O stations
- S7-400H redundant systems
Configuration
- Use STEP 7 software (V5.5 or higher)
- Diagnostic alarms are parameterizable
- Supports firmware updates via SIMATIC Manager

Expert Review / Manager’s Insight

The 6ES7422-7BL00-0AB0 handles high-density output applications well.
Its 32 channels save rack space compared to 16-channel modules.
Diagnostic features reduce troubleshooting time significantly.
Use this module for controlling solenoid valves, contactors, or indicator lights.
For inductive loads, add external flyback diodes for protection.

Typical Applications

Best suited for
- Automotive production lines (conveyor control)
- Chemical plants (valve actuation)
- Water treatment (pump on/off control)
- Packaging machinery (solenoid-driven actions)

Package Contents

Includes
- 1x 6ES7422-7BL00-0AB0 digital output module
- 1x front connector (screw type)
- 1x label strip for channel marking
- 1x quick reference guide

Warranty & Shipping

12-month warranty against manufacturing defects
Same-day shipping for orders before 12:00 GMT
Shipping options: FedEx, UPS, DHL

Frequently Asked Questions

Q: Can I mix 24V DC and 120V AC outputs on this module?
- A: No, this module supports 24V DC outputs only. Use 6ES7422-1BL00-0AA0 for AC applications.
Q: What is the maximum cable length for outputs?
- A: Shielded cable up to 1000 meters, unshielded up to 600 meters.
Q: Does this module support hot-swapping?
- A: No, power down the S7-400 rack before removal or installation.
Q: How do I enable diagnostic alarms?
- A: Configure the module in STEP 7 and enable “Diagnostic interrupt” in the properties.
Q: Can I use this module with ET 200M remote I/O?
- A: Yes, it works with IM 153-1 or IM 153-2 interface modules.
