Product details
Product description:
Precision 5mm eddy-current probe for vibration & position monitoring. Part of the trusted 3300 5mm Proximity Probes family. 1/4-28 UNF thread, unarmored, with PPS tip. Designed for permanent installation in harsh industrial environments (turbines, compressors, pumps).
📞 Need help? WhatsApp +86 18030005825 | ✉ sales@powergearx.com
Model breakdown & ordering options
- 330171 – base series: 3300 5mm probe, 1/4-28 thread, without armor
- 00 – unthreaded length: 0 inch (standard)
- 28 – overall case length: 2.8 inches
- 10 – total length: 1.0 meter (3.3 ft) cable
- 01 – connector: miniature coaxial ClickLoc with connector protector
- 05 – agency approvals: multiple (CSA, ATEX, IECEx)
🔍 Manager’s insight: Reliable 5mm Proximity Probes for radial vibration and thrust position. Preferred for steam turbines, centrifugal compressors, gearboxes. The 1/4-28 thread and 1m cable fit most standard installations. Stock ships same day.
⚙️ Technical specifications
- Measurement range: linear range 2 mm (80 mils) typical, optimized for 1.27 mm (50 mils) gap
- Sensitivity: 200 mV/mil standard (system dependent); output resistance: 50 Ω
- Frequency response: DC to 10 kHz (limited by proximitor)
- Resolution: infinitesimal (eddy-current principle)
- Tip material: Polyphenylene sulfide (PPS); case: AISI 304 SST
- Temperature range: -35°C to +177°C (-31°F to +351°F) probe only
- Environmental tolerance: sealed against oil, dust, moisture; IP rating equivalent
- Immunity: low sensitivity to 60 Hz magnetic fields (≤0.0131 mV pp/gauss at 50 mil gap)
- Power requirement: -17.5 to -26 Vdc, 12 mA max (via proximitor)
- Probe DC resistance: 7.59 Ω ±0.50 (center to outer conductor)
- Tensile strength: 222 N (50 lbf) probe case to lead, lead to connector
🔧 Installation guide
- Mounting thread: 1/4-28 UNF, max thread engagement 0.375 inch (9.5 mm)
- Drill & tap: use #3 or larger tap drill (recommended)
- Recommended torque: 5.1 N·m (45 in·lb) for probe case; max 7.3 N·m (65 in·lb)
- Connector torque: 0.565 N·m (0.42 ft·lb) max
- Minimum cable bend radius: 25.4 mm (1.0 inch)
- Target material: AISI 4140 steel for specified linearity
🛠️ Maintenance, compatibility & approvals
- Ease of Commissioning and Maintenance: Plug and play with Bently Nevada 3300/3300 XL proximitors and extension cables (triaxial, 75Ω). Simple gap setting using standard tools.
- Compatibility: Compatible with all 3300 series 5mm Proximity Probes systems and 3300 XL extensions (part numbers 330130, etc.).
- Certifications: Multiple approvals (CSA, ATEX, IECEx) for hazardous locations; temperature class T2 (177°C) per schedule.
- Package List: 1 x probe 330171-00-28-10-01-05, 1 x installation guide, 1 x inspection certificate.
📦 Delivery & warranty
- Warranty: 12 months from shipment against manufacturing defects.
- Shipping: 12-24 hours (stock item). Express couriers: FedEx, UPS, DHL – tracked and insured.
- Weight: 0.323 kg (probe only).
❓ FAQ –Experience-based Q&A & Purchase Guide
- Q: Can I use this probe with an old 3300 rack?
- A: Yes. It mates with any 3300/3300 XL proximitor. Ensure extension cable type is 75Ω triaxial.
- Q: What is the maximum cable length between probe and proximitor?
- A: Total extension + probe cable up to 9 meters (system dependent). This probe has 1m cable; add 3300 series extension cables.
- Q: My environment exceeds 177°C. What do I do?
- A: This probe is rated 177°C max. For higher temps, consider high-temperature probes or consult factory.
- Q: Which thread type is used – is it compatible with existing holes?
- A: Standard 1/4-28 UNF. Industry common for 5mm Proximity Probes. Check thread engagement depth ≤0.375″.
- Q: Do I need a special tool to tighten the ClickLoc connector?
- A: No. Hand-tighten plus 1/16 turn. Use torque wrench only on probe case (max 7.3 N·m).
- Q: Purchase Guide– 330171 vs 330173, which one to pick?
- A: Choose 330171 (this model) for standard unarmored, 1m cable needs. 330173 series usually include armor or different connector. Compare below.
🔎 Compare with similar Bently Nevada 3300 5mm probes
- 330171-00-28-10-01-05 (this product) – 1/4-28 thread, unarmored, 1m cable, ClickLoc, multiple approvals.
- 330173-00-09-10-02-CN – armored version? Different options, 09 case length, 02 connector. Verify if armor needed for your application.
- 330173-00-02-10-02-CN – 1/4-28, 1m, but 02 case length, different connector; usually for Chinese market variant. Confirm connector compatibility.
- Purchase Guide: Choose 330171 if you need standard miniature ClickLoc (01) and multiple approvals (05). Choose 330173 series if your system specifies armor or specific agency option “CN”.
