Product details
Certified for Explosive Environments
This intrinsically safe 8mm proximity probe (330104-00-12-05-02-05 ) carries multiple international certifications for use in hazardous locations, featuring a compact 12mm case design.
Certification Highlights
- CSA: Certified for Canadian standards
- ATEX: Complies with EU Directive 2014/34/EU
- IECEx: International explosion-proof certification
- Classification: Option 05 approvals package
Model Number Configuration (330104-00-12-05-02-05 )
| Code Segment | Specification |
|---|---|
| 330104 | Base 8mm probe model |
| 00 | 0mm unthreaded length |
| 12 | 12mm case length |
| 05 | 0.5m cable length |
| 02 | ClickLoc connector type |
| 05 | CSA/ATEX/IECEx approvals |
Technical Specifications
- Thread: M10×1 armored thread
- Resistance: 7.45Ω ±0.50Ω at 25°C
- Housing: 304 stainless steel
- Seal: Viton® O-ring (150psi rating)
- Temperature: -40°C to +85°C certified range
Electrical Characteristics
- Power: -17.5Vdc to -26Vdc
- Barrier Voltage: -23Vdc to -26Vdc
- Consumption: 12mA maximum
- Output: 50Ω impedance
Safety Approvals
- ATEX Category 3G (Zone 2)
- IECEx Ex ic IIC T4 Gc
- CSA Class I, Division 2
- Temperature Class T4 (135°C)
Installation Notes
For certified performance, must be installed per drawing 140979 using approved barriers in hazardous locations. Optimal gap setting: 1.27mm (50 mils) on AISI 4140 steel.
Contact Information
Questions? Email: sales@powergearx.com
For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
