Product Overview

The Bently Nevada 3300 XL 8 mm Probe (Product No. 330101-01-13-05-01-05) is a high-performance sensor designed for industrial vibration monitoring. Built with a rugged 8 mm diameter, this probe ensures exceptional durability and reliability in demanding environments. It features advanced technologies like TipLoc and CableLoc for superior performance and includes optional FluidLoc for enhanced resistance to fluid ingress. The “05” suffix indicates compliance with CSA, ATEX, and IECEx standards, making it suitable for hazardous and regulated applications. With a 0.1-inch unthreaded length and a 1.3-inch case length, this probe is ideal for precise installations.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Probe
• Product No.: 330101-01-13-05-01-05
  • 01: Unthreaded Length (0.1 in)
  • 13: Overall Case Length (1.3 in)
  • 05: Total Length (0.5 meter / 1.6 feet)
  • 01: Miniature coaxial ClickLoc connector with connector protector, standard cable
  • 05: CSA, ATEX, and IECEx Approvals

Performance Specifications

• Thread Type: 3/8-24 UNF
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 303 or 304 stainless steel

• Pull Strength: 330 N (75 lbf) with CableLoc design
• Recommended Gap Setting for Radial Vibration: -9 Vdc (~1.27 mm / 50 mils)

Contact Information

For any inquiries, please contact: sales@powergearx.com

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
