330101-00-20-90-02-05 | Proximity Probes – Bently Nevada

Overview

The Bently Nevada 330101-00-20-90-02-05 is a high – quality 3300 XL 8 mm probe manufactured in the U.S.A. It comes with a 3/8 – 24 UNF thread and no armor. With the patented TipLoc molding and CableLoc design, it has significant improvements over previous models. The optional FluidLoc cable can prevent oil and other liquids from leaking through the cable’s interior. The 8 mm probes are more rugged, providing better resistance to physical abuse.

Technical Specification

• Brand: Bently Nevada
• Model: 330101-00-20-90-02-05
  • Suffix Meaning:
    • “00” indicates an unthreaded length of 0.0 inches.
    • “20” represents an overall case length of 2.0 inches.
    • “90” stands for a total length of 9.0 meters.
    • “02” denotes a miniature coaxial ClickLoc connector with a standard cable.
    • “05” represents CSA, ATEX, IECEx approvals.
  • Probe Resistance: The nominal DC resistance from the center conductor to the outer conductor for a 9.0 – meter probe is 9.87 ± 0.50 Ω.
  • Deviation from Best Fit Straight Line: For a 9 – meter system, it is less than ±0.038 mm (±1.5 mil) with components at 0°C to +45°C.
  • Weight: It weighs 323 g/m (11.4 oz).
  • Pressure: The probe is designed to seal differential pressure with a Viton® O – ring, but it is not pressure – tested before shipment.
  • Relative Humidity: There is less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity for up to 56 days.

Contact Information

For any inquiries, please contact: sales@powergearx.com

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
