21504-00-76-05-02 – 7200 Proximity Standard Mount Probe | Bently Nevada

Industrial Vibration Monitoring Solution

Core Specifications

• Model 21504-00-76-05-02 in stock
• 12-month factory warranty
• 193mm (7.6″) extended housing
• 20″ cable (±5″ tolerance)

Technical Parameters

Measurement Range

0.25-2.0mm (10-80 mils)

Linearity Error

±0.02mm (±0.8 mils)

Output Sensitivity

200mV/mil ±9.5%

Frequency Response

0-10kHz (-5% @10kHz)

Mechanical Design

• 3/8-24 UNF threaded mount
• Zero unthreaded installation depth
• Coaxial quick-disconnect connector
• DMF/MEK chemical resistance

Heavy-Duty Applications

• Wind turbine main shaft monitoring
• Mine ventilation fan systems
• Ship engine thrust bearings
• Industrial compressor arrays

Environmental Compliance

Part Configuration

21504-[00]-[76]-[05]-[02]

• 00: 0mm unthreaded

• 76: 193mm (7.6″) case

• 05: 0.5m cable

• 02: MIL-C-39012 connector
