Name: 171CCC76010 Schneider Electric Modicon Momentum M1 Processor Adapter
SKU: 171CCC76010
Price: 266.00 USD
Availability: InStock

Product details

171CCC76010 | Schneider Electric Modicon Momentum M1 Processor Adapter

The 171CCC76010 is a discontinued Modicon Momentum M1 processor adapter from Schneider Electric. It brings control intelligence to Momentum I/O bases. Engineers choose it for compact machines, legacy Modbus RTU networks, and distributed control panels. The module uses a 32 MHz M1 processor. It offers 512 KB Flash program memory and 24 KB data registers. A single RS-232 DB9 port handles Modbus RTU serial communication. Expansion adapters add Ethernet, Modbus Plus, PROFINET, or S908 RIO. The unit draws 5 V DC from the Momentum I/O base. Its IP20 rating suits cabinet-protected installations. This adapter is a practical spare for existing Momentum systems. It also supports migration planning for older automation lines.

Technical Data

Brand: Schneider Electric
Model: 171CCC76010
Series: Modicon Momentum
Product type: M1 Processor Adapter
Processor: M1 series, 32 MHz
Math coprocessor: Not available, X86-based
Program memory: 512 KB Flash
Data memory: 24 KB data registers
Internal RAM: 512 KB
Programming software: Concept V2.6, ProWORX 32, Modsoft
Scan speed: 1 ms per 1K instruction
I/O bus: Momentum I/O bus
Discrete I/O max: 8192 in / 8192 out
Analog I/O max: 26048 register I/O
Built-in port: 1 x RS-232 serial, DB9
Protocol: Modbus RTU serial
Communication expansion: 170ANE Ethernet, 170INT Modbus Plus, 170PNT PROFINET, 170CRA S908 RIO
Supply voltage: 24 V DC
Power consumption: Supplied by Momentum I/O base, 5 V DC
Protection rating: IP20
Dimensions: 125 x 141.5 x 47.5 mm
Weight: 0.14 kg
Lifecycle: Discontinued, last verified 2026-09

Core Performance Details

Measurement range: Not applicable for this processor adapter
Frequency response: Not applicable for this control module
Sensitivity: Not applicable for this digital processor
Linearity: Not applicable for this logic adapter
Resolution: Determined by installed Momentum I/O modules
Temperature range: Not available from published data
Environmental tolerance: IP20 cabinet protection only
Noise immunity: Designed for industrial control cabinets

Installation Guide

Mount the adapter on a compatible Momentum I/O base.
Confirm 24 V DC supply and 5 V DC base power.
Connect the DB9 RS-232 cable for Modbus RTU.
Add a communication adapter for Ethernet or fieldbus.
Keep the module inside an IP20-rated enclosure.
Check terminal torque and cable strain relief.

Debug and Maintenance Convenience

Use Concept V2.6, ProWORX 32, or Modsoft for diagnostics.
Monitor scan time against the 1 ms per 1K instruction rating.
Replace the adapter without rewiring the full I/O base.
Keep spare communication adapters for faster repairs.
Label RS-232 and expansion ports clearly.

Compatibility Notes

Works with Modicon Momentum I/O bases.
Supports Modbus RTU over the built-in RS-232 port.
Accepts 170ANE, 170INT, 170PNT, and 170CRA adapters.
Programs with Concept V2.6, ProWORX 32, and Modsoft.
Not compatible with modern EcoStruxure Control Expert unless migrated.

Certifications and Compliance

Certification details are not available in the supplied data.
Confirm local electrical and EMC rules before installation.
Use original Schneider Electric documentation for final approval.

Package Contents

1 x Schneider Electric 171CCC76010 M1 Processor Adapter
Protective packaging for safe transport
Order confirmation and commercial invoice

Warranty and Shipping

Warranty: 12 months
Dispatch: 12 to 24 hours after order confirmation
Couriers: FedEx, UPS, DHL
Tracking: Shared after shipment

Expert Review

The 171CCC76010 remains a strong choice for legacy Momentum users. Its 32 MHz M1 processor handles compact control tasks well. The 512 KB Flash memory and 24 KB data registers suit small to medium programs. Modbus RTU over RS-232 keeps integration simple. Expansion adapters add modern network options without changing the base. The main drawback is its discontinued status. Buyers should stock spares before failures stop production. For existing lines, this adapter offers low-risk replacement. For new projects, consider a newer Modicon platform.

Manager’s Insight

This module appeals to maintenance teams and system integrators. It solves fast replacement needs in older Momentum panels. The 1 ms scan speed supports responsive machine control. Its IP20 rating fits clean cabinets, not harsh washdown areas. The RS-232 port limits distance and speed. Add a 170ANE or 170PNT adapter when network speed matters. The 12-month warranty and 12 to 24 hour dispatch reduce downtime risk. Keep at least one spare on site. That simple step protects uptime better than any upgrade plan.

Best Suited Equipment and Applications

Buying Guide

Check your existing Momentum base part number first.
Confirm you need the M1 processor adapter, not an I/O module.
Match the RS-232 port to your Modbus RTU network.
Choose a communication adapter for Ethernet or fieldbus.
Verify Concept V2.6, ProWORX 32, or Modsoft availability.
Order spare units because the product is discontinued.
Ask for firmware and revision details before purchase.

FAQ

What is the 171CCC76010?
It is a Modicon Momentum M1 processor adapter from Schneider Electric.
Is this module still active?
No. It is discontinued and last verified in September 2026.
Which software programs it?
Concept V2.6, ProWORX 32, and Modsoft support this adapter.
How much program memory does it have?
It includes 512 KB Flash and 512 KB internal RAM.
What communication port is built in?
It has one RS-232 DB9 port for Modbus RTU.
Can I add Ethernet?
Yes. Use a 170ANE communication adapter on the Momentum backplane.
What is the scan speed?
It scans about 1 ms per 1K instruction.
What voltage does it use?
It uses 24 V DC and draws 5 V DC from the I/O base.
What is the protection rating?
It carries an IP20 rating for cabinet use.
What is the warranty?
It comes with a 12-month warranty.
How fast do you ship?
Orders dispatch within 12 to 24 hours.
Which couriers do you use?
We ship by FedEx, UPS, and DHL.
Do you have experience with this part?
Yes. Our team supports legacy Modicon users daily.
Can you help me choose a spare?
Yes. Share your base model and we will confirm fit.
What should I check before buying?
Confirm your base, software, port type, and network adapter needs.
Do you offer technical guidance?
Yes. Contact us before ordering for compatibility checks.
