170ADI54050 Schneider Modicon Momentum Discrete Input Base 120V AC

170ADI54050 | Schneider Electric Modicon Momentum Discrete Input Base

The 170ADI54050 is a discrete input base from Schneider Electric. It belongs to the Modicon Momentum line. Moreover, it offers 16 channels in 2 groups of 8 inputs. It works with 120V AC input signals. As a result, it suits general automation jobs. It also uses TC Treatment for tough sites. In addition, it carries the CE mark. Therefore, it is a solid pick for mid-level control tasks.

Technical Data

• Brand: Schneider Electric
• Model: 170ADI54050
• Series: Modicon Momentum
• Product Type: Discrete Input Base
• EAN / GTIN: 3595861147522
• Channels: 16
• Groups: 2 groups of 8 inputs
• Input Voltage: 120V AC
• Input Logic: Positive
• Input Voltage Limits: 85 to 132V AC
• Network Frequency: 47 to 63 Hz
• Voltage Range: 0 to 132V
• Protective Treatment: TC
• Marking: CE

Core Performance Details

• Measurement Range: 0 to 132V
• Frequency Response: 47 to 63 Hz
• Sensitivity: Set by the 120V AC input design
• Linearity: Not available
• Resolution: Not available
• Temperature Range: 0°C to 60°C operating
• Environmental Tolerance: Up to 95% relative humidity, no condensation
• Anti-interference Ability: 1780V AC isolation between groups and between channels and bus

Isolation and Signalling

• Isolation between groups: 1780V AC
• Isolation between channels and bus: 1780V AC
• Local Signalling: 16 LEDs for channel status
• Terminal Labels: (N)PW, (L1)PW, TB, IN_DIS#1 to IN_DIS#16

Physical Data

• Height: 141.5 mm (5.6 in)
• Width: 125 mm (4.9 in)
• Depth: 47.5 mm (1.9 in)
• Net Weight: 0.284 kg (0.626 lb)

Environmental Data

• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Maximum Relative Humidity: 95% without condensation
• Protective Treatment: TC

Installation Guide

• Mount the base on a Modicon Momentum rail or slot.
• Use 120V AC for the input lines.
• Keep voltage inside 85 to 132V AC.
• Wire each input to its IN_DIS terminal.
• Check the positive input logic before power on.
• Keep the unit in a dry, clean panel.

Commissioning and Maintenance

• Watch the 16 LEDs for channel status.
• Test each group of 8 inputs after wiring.
• Check the 47 to 63 Hz supply match.
• Clean with a dry cloth only.
• Retighten terminals after vibration.
• Replace the base if a channel fails.

Compatibility Notes

• Fits the Modicon Momentum automation platform.
• Works with 120V AC discrete input signals.
• Uses positive input logic.
• Needs a supply within 85 to 132V AC.
• Confirm your base type before you order.

Certifications and Compliance

• CE marked.
• TC protective treatment.
• Follow local rules for 120V AC wiring.
• Keep proof of purchase for claims.

Packing List

• 1 × 170ADI54050 Discrete Input Base
• 1 × Protective packing
• 1 × Order confirmation
• 1 × Warranty document

Warranty and Shipping

• Warranty: 12 months
• Dispatch: 12–24 hours after payment
• Couriers: FedEx, UPS, DHL
• Tracking: Shared once the parcel ships
• Support: Technical help on request

Compare With Other Models

• 170ADI54050 vs 170PNT11020: the first is a 120V AC input base; the second is a Modbus Plus adapter.
• 170ADI54050 vs 170ADI35000: both are input bases; check channel count and voltage before you buy.
• 170ADI54050 vs 170AAI14000: the first handles discrete AC inputs; the second handles analog inputs.
• 170ADI54050 vs 170ADO35000: the first reads inputs; the second drives outputs.
• 170ADI54050 vs 170ADM35010: the first is input only; the second mixes input and output.

Expert Review

The 170ADI54050 does one job well: it reads 120V AC discrete signals. The 16 channels split into 2 groups of 8. This layout helps when one group fails. The 1780V AC isolation protects the bus. The CE mark and TC Treatment add trust. The 0°C to 60°C range fits most plants. The 16 LEDs make troubleshooting fast. However, it is not a smart module. Still, it is a sturdy input base for legacy lines.

Manager’s Insight

Keep one 170ADI54050 in your spares bin. Line stops cost more than the part. The 12-month warranty and 12–24 hour dispatch cut risk. Use FedEx, UPS, or DHL for fast delivery. Check your Modicon Momentum base first. Confirm the 120V AC supply and positive logic. Train staff on the 16 LEDs. As a result, this cuts downtime a lot.

Best Fit Devices and Applications

• Modicon Momentum control racks
• General factory automation
• Mid-level machine control
• Packaging and assembly lines
• Material handling systems
• Water and pump stations
• Panel builders and system integrators
• Legacy plant upgrade projects

FAQ

Q: How many inputs does this base read?

A: It reads 16 inputs. They sit in 2 groups of 8.

Q: What input voltage does it need?

A: It needs 120V AC. The safe window is 85 to 132V AC.

Q: Does it work at 50 Hz and 60 Hz?

A: Yes. It runs from 47 to 63 Hz. That covers both common grid rates.

Q: How do I know a channel is on?

A: Each channel has an LED. The base shows 16 LEDs in total.

Q: What is the warranty?

A: We give 12 months. Keep your invoice for claims.

Q: How fast do you ship?

A: We dispatch in 12–24 hours. We use FedEx, UPS, and DHL.

Q: Can I use it in a wet area?

A: It handles up to 95% humidity without condensation. Keep it in a dry panel.

Q: What should I check before buying?

A: Confirm the Modicon Momentum base, the 120V AC supply, and the positive logic. Ask us if unsure.

Buying Guide

• Confirm your rack fits the Modicon Momentum line.
• Check your field devices use 120V AC.
• Count your input points. You get 16 channels.
• Plan for the 0°C to 60°C range.
• Keep a spare for critical lines.
• Ask us for stock and lead time.
• Share your base model for a fit check.
