1606-XLB240E Allen-Bradley 24V 240W DIN Rail Power Supply

1606-XLB240E | Allen-Bradley | Bulletin 1606-XL | 24V DC 240W Switched-Mode Power Supply

Description

This 1606-XLB240E power supply delivers reliable 24V DC output at 240W. It belongs to the Allen-Bradley Bulletin 1606-XL series. The unit uses switched-mode technology. It suits industrial automation and control panels. No communication interface exists. It focuses on stable power conversion. The DC OK relay contact helps monitor output status. DIN rail mounting saves panel space. Screw terminals make wiring simple. This model is current and listed in Bulletin 1606-TD002.

Key Attractions

• High efficiency: 95.2% typical. Less heat. Lower energy cost.
• Adjustable output: 24 to 28V DC. Fine-tune for your load.
• Robust input: 100 to 240V AC. Works worldwide.
• Compact body: 124 x 49 x 124 mm. Fits tight spaces.
• Reliable relay: DC OK contact for status feedback.

Technical Data

• Brand: Allen-Bradley
• Model: 1606-XLB240E
• Series: Bulletin 1606-XL
• Type: Basic switched-mode power supply
• Output voltage: 24V DC nominal, adjustable 24…28V
• Output current: 10A nominal, 10…8.6A range
• Rated power: 240W
• Input voltage: AC 100…240V
• Efficiency: 95.2% typical
• Power losses: 12.1W typical
• Ripple and noise: 100 mVpp maximum
• Power factor: 0.93 typical
• Derating: 6W/°C from +60…+70°C
• Operating temperature: -25…+70°C
• Storage temperature: Not published by manufacturer
• Relative humidity: Not published by manufacturer
• Protection rating: IP20 (open-frame, DIN-rail)
• Dimensions (HxWxD): 124 x 49 x 124 mm
• Weight: 0.54 kg
• Communication ports: None
• Protocols: None
• Mounting: DIN rail
• Terminals: Screw terminals
• Special feature: DC OK relay contact

Installation Guide

• Step 1: Snap unit onto DIN rail. Use 35mm rail.
• Step 2: Connect input wires to screw terminals. Observe L and N polarity.
• Step 3: Connect load to output terminals. Keep wires short.
• Step 4: Adjust output voltage if needed. Use trim pot. Range is 24 to 28V DC.
• Step 5: Wire the DC OK relay contact to a monitor or PLC. It signals output health.
• Step 6: Ensure IP20 environment. Keep away from dust and moisture.
• Step 7: Allow airflow. Do not block vents. Derate above +60°C.

Commissioning and Maintenance

• Check output voltage before connecting sensitive loads.
• Verify DC OK relay changes state when output is normal.
• Clean terminals periodically. Use dry cloth.
• No internal fuses. Protect upstream with circuit breaker.
• No communication means no software setup. Simple and fast.

Compatibility Notes

• Works with Allen-Bradley PLC racks and I/O modules.
• Compatible with 24V DC sensors, relays, and solenoids.
• Suits Bulletin 1606-XL accessory buffers and redundancy modules.
• No protocol means no network integration. Use as standalone power source.
• Can replace similar 240W DIN-rail supplies from other brands.

Certifications

• UL 60950-1 recognized
• cUL listed
• CE marked
• Complies with Bulletin 1606 series standard

Packaging List

• 1 x 1606-XLB240E power supply unit
• 1 x Quick start guide (basic wiring)
• 1 x DIN rail clip (pre-installed)
• No communication cable included

Warranty and Shipping

• Warranty: 12 months from date of delivery.
• Dispatch time: 12 to 24 hours after payment clears.
• Couriers: FedEx, UPS, DHL. Tracking provided.
• Contact for inquiries: sales@powergearx.com or +86 18030005825 (WhatsApp).

Expert Review

This 1606-XLB240E is a workhorse. It does one job well: convert AC to stable 24V DC. The 95.2% efficiency keeps panels cooler. The DC OK relay is a rare find in basic supplies. It gives you early warning if output drifts. No communication port means no complexity. That is a plus for simple machines. The IP20 rating limits use to clean cabinets. Adjustable output helps with long cable runs. Derating above 60°C is standard. For system integrators, this unit saves wiring time. It snaps on DIN rail. Screw terminals accept solid and stranded wire. The Allen-Bradley brand ensures documentation and support. This is a smart pick for OEM panels and retrofits.

Manager’s Insight

Stock this model if you serve industrial automation clients. It fits PLC racks, sensor networks, and relay logic. The 240W rating covers many mid-size loads. No communication keeps cost low. But the DC OK contact adds value. Competitors often lack this. Lead time is short. Ship within 12 to 24 hours. Offer FedEx, UPS, DHL options. Customers get tracking fast. The 12-month warranty matches market standard. Use the UL/cUL/CE approvals as selling points. Target panel builders and maintenance teams. This unit replaces older 1606-XL models without rewiring. That is a strong upgrade path.

Ideal Equipment and Applications

• PLC control cabinets (Allen-Bradley CompactLogix, MicroLogix)
• Sensor and actuator loops (24V DC inductive and capacitive)
• Relay and timer circuits (industrial logic)
• Human-machine interfaces (HMIs) and panel PCs
• Building automation (HVAC, lighting control)
• Test benches and lab power distribution
• Retrofit projects replacing older linear supplies

FAQ

Q: Does this power supply have any network port?

A: No. It has no communication interface. No Ethernet, no serial, no fieldbus. It works as a standalone power source. You monitor it via the DC OK relay contact.

Q: Can I adjust the output above 24V?

A: Yes. The trim pot allows 24 to 28V DC adjustment. Turn clockwise to increase. Use a multimeter to set precisely.

Q: What is the derating rule?

A: Derate 6W per °C from +60 to +70°C. For example, at 65°C, max output drops to about 210W. Keep cabinet temperature below 60°C for full power.

Q: Is this unit UL listed?

A: It meets UL 60950-1 and cUL. It carries the CE mark. These are standard for Bulletin 1606 series.

Q: How fast do you ship?

A: We dispatch in 12 to 24 hours. We use FedEx, UPS, DHL. You get a tracking number by email.

Q: What is the warranty?

A: 12 months from delivery. Covers manufacturing defects. Does not cover misuse or incorrect wiring.

Q: Does it come with mounting screws?

A: No screws for the DIN rail. The unit has a built-in clip. You only need a standard 35mm rail. Screw terminals are on the front.

Q: Can I use this for battery charging?

A: No. It is a power supply, not a charger. It does not have charging logic. Use a dedicated charger for batteries.

Q: What if I need communication?

A: Choose a different model. The 1606-XL series has variants with IO-Link or Ethernet. This 1606-XLB240E is the basic version.

Q: How do I know the output is OK?

A: The DC OK relay closes when output is within range. Wire it to a lamp or PLC input. If the relay opens, output has failed.

Buying Guide

• Check your load: Add up all 24V devices. Keep total below 10A (240W).
• Check input: Your AC supply must be 100 to 240V. Single phase.
• Check space: The unit is 49mm wide. Allow 20mm clearance for airflow.
• Check environment: IP20 only. Use inside a cabinet. Avoid condensation.
• Check monitoring: Need status? The DC OK relay is your friend.
• Check brand: Allen-Bradley gives you global support and docs.
• Check warranty: 12 months is standard. Keep your invoice.
• Check shipping: Fast dispatch via FedEx, UPS, DHL. Order before 2pm for same-day.
