CP 216 High-Temperature Pressure Transducer – Extreme Environment Performance
The CP 216 piezoelectric pressure transducer handles extreme temperatures from -70°C to 520°C. This reliable sensor measures dynamic pressure up to 350 bar in tough industrial applications.
Critical Performance Data
- Manufacturer: Vibro-Meter®
- Product Model: CP 216 Series
- Pressure Sensitivity: 200 pC/bar
- Temperature Range: -70°C to 520°C
- Pressure Range: 0.0005 to 250 bar
- Frequency Response: 2 Hz to 15 kHz
- Overload Capacity: 350 bar maximum
- Product Warranty: 12 months
Advanced Technical Specifications
- Resonant frequency exceeds 80 kHz
- Linearity better than ±1% across range
- Acceleration sensitivity: ≤ 0.5 pC/g
- Shock resistance: 2000 g peak
- Internal insulation: > 10⁹ Ω
- Gamma radiation resistant: 10¹⁰ erg/g
- Neutron flux tolerance: 10¹⁷ n/cm²
Environmental Capabilities
- Continuous operation: -54°C to 470°C
- Extreme temporary use: -70°C to 520°C
- NIMONIC alloy 90 construction
- Hermetically welded housing
- Mineral insulated cable standard
- Explosive atmosphere certified
Electrical Characteristics
- Pole-to-pole capacitance: 320 pF
- Cable capacitance: 200 pF/meter
- Case insulation: 13 pF
- No external power required
- Charge output signal type
- Two-pole insulated system
Physical Properties
- Ultra-lightweight: 12 grams
- Cable weight: 25 grams/meter
- Mineral insulated cable
- LEMO or high-temperature connector
- Compact design for tight spaces
Product Selection Guide
- Base Reference: 143-216-000-2XX
- Model Variants:
- 143-216-000-251 → Standard LEMO
- 143-216-000-252 → High-temp connector
- 143-216-000-253 → Custom cable length
- All units include factory calibration
Delivery Information
- Protective shipping container
- Calibration documentation
- Technical data sheet
- Global express delivery available
- Carriers: FedEx, UPS, DHL
- 12-month quality guarantee
Expert Technical Support
- What applications suit the CP 216 transducer?
- Gas turbine monitoring and high-temperature pressure testing
- How does temperature affect performance?
- Maintains accuracy from -70°C to 520°C with minimal deviation
- What connector options are available?
- Standard LEMO or special high-temperature connector to 650°C
- Can it measure static pressure?
- Designed for dynamic pressure; measures rapid pressure changes
- Is radiation resistance tested?
- Yes, withstands gamma and neutron radiation in nuclear applications
