Yaskawa SGMG-09A2AB Servo Motor Overview
The Yaskawa SGMG-09A2AB motor gives fast motion and strong torque. It fits many machines that need smooth control. And it uses a synchronous AC design for stable work. It offers clear feedback with an 8192 P/R encoder. It starts fast and stops with high accuracy. Content by Powergear X Automation.
Main Features
- Rated power: 850 W for strong load work
- Torque: 5.39 Nm for sharp motion
- Rated speed: 1500 RPM for stable use
- Peak speed: 3000 RPM when needed
- Shaft: Straight type with key and tap
- Encoder: 8192 P/R incremental type for fine control
- Supply: 200 VAC main circuit
- Current: 7.1 A for strong drive force
- Mounting: Flange style for easy fit
- Protection: IP44 for splash safety
- Insulation: Class F for better heat strength
- Work temp: 0–40°C in dry air
- Store temp: -20–80°C
- Weight: 2.27 kg for light handling
- Fast start and good low-speed smoothness
- Low noise and low vibration build
- Strong housing for long use life
Extra Technical Points
- Rotor balance design reduces shake
- High thermal headroom for long duty cycles
- Windings tuned for steady torque curve
- Quick encoder response for tight loops
- Stable output during voltage swings
Why This Motor Works Well
- Simple wiring for fast setup
- Good match with Sigma drives
- Durable shaft for repeat loads
- High resolution feedback for clean paths
- Fits compact machines
Applications
- Robotic arms with tight motion paths
- Pick-and-place units
- Precision conveyors
- Machine tools
- Inspection systems needing fine steps
Shipping and Warranty
- Ships by FedEx, UPS, or DHL
- Warranty: 12 months
- Safe shock-proof packing
FAQ
How can I get the best torque?
You can keep the motor within its rated load and check the drive tune.
How can I avoid heat buildup?
You can leave space around the motor and clean dust often.
Why does the encoder matter?
The high resolution helps your machine hold tight positions.
How do I reduce shaft stress?
You can use proper coupling and align the load well.
How can I get smoother starts?
You can tune the drive gain and check for friction in the machine.
Need the Manual?
- You can request the full guide from our support team.
- We also help with tuning tips.
