Overview
Woodward 5464-654 Discrete Output Module delivers fast, reliable relay control for industrial prime movers.
It supports MicroNet systems with precise and responsive discrete output handling.
Engineers select 5464-654 for its predictable performance, fast update time, and clear fault diagnostics.
Technical Specifications
- Brand: Woodward
- Model: 5464-654
- Category: Discrete Output Module for MicroNet Systems
- Number of Channels: 32
- Update Time: 5 ms
- System Faults: Outputs turn off if CPU communication is lost.
- Relay Interface: Non-isolated relay driver signals with external 24 Vdc power supply.
- Mounting: Panel mount, dual handles for easy removal, secure chassis screws.
- Country of Manufacture: United States (USA)
Installation Guide
- Insert the module into the MicroNet chassis card guides carefully.
- Secure with top and bottom screws and toggle handles for firm connection.
- Provide a separate 24 Vdc power source for relay operation.
- Connect low-density discrete cables between relay modules following proper labeling.
Packaging List
- 1 × Woodward 5464-654 Discrete Output Module
- Mounting screws and detachable front handles
- Quick installation reference sheet
- Protective packing foam for safe transit
- Delivery via FedEx, UPS, or DHL with tracking
Shipping & Logistics
- Orders shipped worldwide via FedEx, UPS, or DHL.
- Tracking numbers provided for all shipments.
- Expedited and standard shipping options available.
- Contact sales for palletized freight or bulk order handling.
FAQ
- What power supply is required for the 5464-654?
- A separate 24 Vdc power source is needed for relay operation.
- Can the 5464-654 be replaced without recalibration?
- Yes, simply replace it with another module of the same part number. No calibration needed.
- What happens if the CPU loses communication?
- The module automatically disables all outputs to prevent unsafe operation.
