Woodward 5464-648 8-CH 4-20mA Analog Output Module for Turbine Control

Overview

Woodward’s 5464-648 delivers reliable analog control with eight precise 4-20mA channels and built-in diagnostics for high-performance turbine systems.

Technical Specifications

• Model and Brand: Woodward 5464-648, Analog 8-Channel Output Module (4-20mA) for gas turbine and automation systems.
• Dimensions & Weight: 16cm × 16cm × 12cm, 0.91 kg compact enclosure for panel or rack installations.
• Channels & Signal Type: Eight independent channels support 4-20mA analog current output for precision control.
• Resolution & Accuracy: 16-bit digital-to-analog conversion with ±0.1% full-scale accuracy ensures smooth output.
• Update Rate & Linearity: Refresh rate of 10 ms per channel and linearity within 0.1% FS guarantee consistent signals.
• Operating Temperature: Works from -20°C to 70°C to meet harsh industrial environmental demands.
• Isolation & EMI Immunity: 1500 Vrms isolation and built-in EMI suppression improve system reliability.
• Load Compliance: Supports up to 600 Ω loop resistance per channel for field instrumentation.
• Communication & Configuration: Compatible with industrial standards for PLC/DCS integration and easy setup.
• Diagnostics & Indicators: LED indicators show channel health, and self-diagnostics detect output faults instantly.

Packing List

• 1 × Woodward 5464-648 analog output module
• 1 × Set of mounting screws
• 1 × Quick-start wiring and installation guide
• Protective anti-static and foam packaging for transport safety

Shipping & Delivery

• Worldwide shipping via FedEx, UPS, or DHL with tracking and insured delivery.
• Each unit is visually inspected and functionally verified before shipment.
• Modules are securely packed in anti-static material to ensure transit protection.

FAQ

• Q: Which systems are compatible with the 5464-648?
  A: It integrates easily with PLC or DCS platforms using standard industrial protocols.
• Q: Does it provide isolation between channels?
  A: Yes, each channel is electrically isolated to protect both system and sensors from cross-interference.
• Q: How can I verify output functionality during startup?
  A: Use a calibrated loop tester to measure 4-20mA outputs while adjusting the control reference.

Manufacturer & Series

• Woodward 5464-648 belongs to Woodward’s analog control module line, designed for turbine and automation systems.
• All modules maintain industry-leading precision, reliability, and configurable flexibility for long-term applications.
