Universal Input/Output Module 900U01-0100: Flexible Industrial Control
The Universal I/O Module 900U01-0100 offers complete configuration flexibility. This 16-channel module adapts to your specific control needs. It supports analog and digital signals with HART communication. The module provides reliable performance for diverse industrial applications.
Technical Specifications
- Model Number: Universal I/O Module 900U01-0100
- Total Channels: 16 software-configurable I/O points
- Isolation Rating: 1000V AC between logic and field
- Field Voltage: 22-27V DC with 24V typical operation
- Power Capacity: 4.2A maximum per module
- Analog Resolution: 16-bit for inputs, 12-bit for outputs
- Accuracy: 0.1% full-scale at room temperature
- Input Range: 0-20mA or 4-20mA current signals
- Output Capacity: 0.5A maximum per digital channel
- Temperature Range: 0 to +60°C operating environment
Configuration Options
- Analog Input with HART communication support
- Analog Output with 4-20mA current loops
- Digital Input with open wire detection
- Digital Output with short-circuit protection
- Mixed configurations across all 16 channels
- Fail-safe settings for critical applications
Shipping & Warranty
- 12-month comprehensive warranty
- Global express shipping via FedEx, UPS, DHL
- Complete documentation and manuals included
- Mounting hardware provided for easy installation
- Real-time package tracking for all orders
- Technical support available for setup questions
Frequently Asked Questions
How many signal types can this module handle?
It supports analog inputs, analog outputs, digital inputs, and digital outputs.
What is the maximum current per channel?
Digital outputs handle 0.5A per channel with 4.2A module maximum.
Does it support HART communication protocol?
Yes, both analog input and output channels support HART protocol.
What isolation protection does it provide?
The module offers 1000V AC isolation between logic and field sides.
Can I mix different signal types on one module?
Yes, all 16 channels can be individually configured as needed.
